AMITSUBISHI
AM/FM STEREO
TUNER-PREAMPLIFIER
DA-CZU
SERVICE MANUAL
Amt "mm «. 4 A
CONTENTS
SPECIFICATION ............................................................ 2
SERVICING NOTES ...................................................... 5
DESCRIPTION AND FUNCTION OF EACH PART --------- 7
DISASSEMBLING 8
ADJUSTMENT ............................................................... 1O
THREADING ON DIAL ................................................... 12
PRINTED CIRCUIT BOARD ............................................. 13
SCHEMATIC DIAGRAM ................................................ 19
WIRING ........................................................................ 23
PARTS LIST .................................................................. 25
PACKAGE INSTRUCTION ............................................. 25
MELCO SALES, INC.
