Page 2
V-TWIN
MISC PARTS
Control Function
Jacks
Type
Mesa Pa rt#
Mixer/Headphone Jack 612391
All Remaining (5) Jack 618112
Power Jack 612712
Mixer/Phones Switch 601901
AC Adapter Domestic 540122
FRONT PANEL
MISC PARTS
Control Function Type Mesa Part# Control Function Type Mesa Part#
Gain Pot 594737 Bypass Switch 600400
Knob 408120 Channel " " 600400
Bass Pot 594739 Clean/Blues
Knob 408120 Cap 600203
Middle Pot 594737 Shaft 600201
Knob 408120 Plunger 600202
Treble Pot 594149 LEDs
Knob 408120 Bypass Lens 703300
Presence Pot 594739 LED 395753
Knob 408120 Clean Lens 703300
Master Pot 594378 LED 395438
Knob 408120 Blues Lens 703300
LED 395439
Solo Lens 703300
LED 395753
Tube Cage 493620
Thumb Screw 302063
REAR PANEL
