Mesaboogie v1 bottle rocket schematics
This is the 4 pages manual for mesaboogie v1 bottle rocket schematics.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Page: 1 / 4
Extracted text from mesaboogie v1 bottle rocket schematics (Ocr-read)
Page 1
V] Bottle Rocket
Page 2
V-l Bottle Rocket
FRONT PANEL
MISC PARTS
Control Function Type Mesa Part# Control Function Type Mesa Part#
Gain Pot 593739 Bypass Switch 600105
Knob 408200 Channel " "
Bass Pot 593739 Tube Cage 491012
Knob 408200 Thumb Screw 302063
Treble Pot 593148
Knob 408200
Output Pot 593151
Knob 408200
REAR PANEL
MISC PARTS
Control Function Type Mesa Part#
Amplifier Jack 6181 12
Guitar Jack 618112
Power Jack 613712
AC Adapter Domestic 540122
