McIntosh XRT 2K Owners Manual
This is the 24 pages manual for McIntosh XRT 2K Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from McIntosh XRT 2K Owners Manual (Ocr-read)
Page 1
2 IMPOR T ANT SAFETY INSTRUCTIONS! PLEASE READ THEM BEFORE OPERATING THIS EQUIPMENT. WARNING - TO REDUCE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. To prevent the risk of electric shock, do not remove cover or back. No user serviceable parts inside. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a non-abrasive dry soft cloth. 7. Install in accordance with the manufacturersinstructions. 8. This Loudspeaker is capable of pr oducing extr emely high sound pr essur e levels, even when connected to amplifiers of moderate power output. User caution is advised. Ear pr otection is r ecommended when playing at high volumes as continued exposur e to high sound pr essur e levels can cause permanent hearing impairment or loss. The use of a Sound Level Pr essur e Meter will gr eatly aid in determining when high volume levels ar e occurring. 9. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 10. Only use attachments/accessories specified by the manufacturer. 11. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 12. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 13. Do not expose this equipment to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the equipment. 14. W ARNING: When this Loudspeaker is connected to an amplifier that is Power ed On, the connection terminals may have hazardous live voltages pr esent with a risk of electric shock. 15. CAUTION: When this Loudspeaker is assembled it weighs 452 pounds (205.0 kgs). It requir es four or mor e persons to safely move the Loudspeaker .
Page 2
3 Customer Service Technical Assistance Please Take A MomentThank You Copyright 2005 © by McIntosh Laboratory, Inc. The serial number, purchase date and McIntosh Dealer name are important to you for possible insurance claim or future service. The spaces below have been provided for you to record that information: Your decision to own this McIntosh XRT2K Loudspeaker System ranks you at the very top among discriminating mu- sic listeners. You now have The Best. The McIntosh dedi- cation to Quality, is assurance that you will receive many years of musical enjoyment from this unit. Please take a short time to read the information in this manual. We want you to be as familiar as possible with all the features and functions of your new McIntosh. Serial Number: Purchase Date: Dealer Name: If it is determined that your McIntosh product is in need of repair, you can return it to your Dealer. You can also return it to the McIntosh Laboratory Service Department. For as- sistance on factory repair return procedure, contact the McIntosh Service Department at: McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-3515 Fax: 607-723-1917 If at any time you have questions about your McIntosh product, contact your McIntosh Dealer who is familiar with your McIntosh equipment and any other brands that may be part of your system. If you or your Dealer wish additional help concerning a suspected problem, you can receive tech- nical assistance for all McIntosh products at: McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-1545 Fax: 607-724-0549 Safety Instructions Table of Contents Safety Instructions ............................................................. 2 Thank You and Please Take a Moment .............................. 3 Technical Assistance and Customer Service ...................... 3 Table of Contents and Important Information .................... 3 Introduction ........................................................................\ 4 Performance Features ........................................................ 5 Dimensions ...................................................................... 6-8 Unpacking and Assembly .............................................. 9-10 Room Placement .............................................................. 11 Midrange/High Frequency Column, Low Frequency Col- umn Base Connections ..................................................... 12 Low Frequency Column Rear Panel Connections ............ 13 How to Connect using a single amplifier ......................... 14 How to Connect using two amplifiers .............................. 16 How to Connect using three amplifiers ............................ 18 Photos ........................................................................\ . 20-21 Specifications ................................................................... 22 Packing Instruction .......................................................... 23 Caution: The XRT2K when assembled weight is 452 pounds (205.0kg). It requires four or more persons to safely handle the Loudspeaker System. 1. Loudspeaker Cables of adequate size are important to ensure that there will be no significant power loss or heating. Cable size is specified in Gauge numbers or AWG (American Wire Gauge). The smaller the Gauge number, the larger the wire size: If the Loudspeaker Cables are 50 feet (38.1m) or less, use at least 12 Gauge (AWG) wire size or larger. If the Loudspeaker Cables are 100 feet (76.2m) or less, use at least 10 Gauge (AWG) wire size or larger. 2. For additional connection information, refer to the ownersmanual(s) for any component(s) connected to the XRT2K Loudspeaker. 3. The XRT2Ks built-in speaker protection incorporates five automatic resetting solid-state devices in the crossover networks. One protects the tweeters, one for the midranges and three for the woofers. The protection allows a certain amount of overdrive but extended periods will trigger protection. If an obvious lack of high, mid or low frequencies is noticed, the Protection Device may have activated. These devices will automatically reset when the volume level is reduced significantly and kept low until the output of the affected Loudspeaker Element returns to normal. 4. When the XRT2K Loudspeaker System is driven by more than one amplifier, the output levels of the different amplifiers connected to the Loudspeaker System must be adjusted to achieve a proper balance between the low, midrange and high frequencies reproduced. This adjustment is best achieved through the use of audio test equipment operated by a qualified installer. Important Information
Page 10
11 Room Placement Room Placement Loudspeaker placement in a room can greatly affect performance. The XRT2K Loudspeaker is designed for both Music and Home Theater Systems. The optimal method for selecting speaker locations includes the use of a real time spectrum analyzer operated by an experienced system installer. An uncompromising installation would take into consideration the floor, wall and ceiling coverings, the type and placement of furniture and can even include the architectural design of the room and its construction materials. In those instances where placement in the room is fixed an environmental equalizer may be needed to restore proper musical balance. Placement near a wall, corner, floor, ceiling or any inter- secting surfaces will reinforce some bass frequencies. Which bass frequencies are boosted by placement in a par- ticular location is dependent on the dimensions of the room. Test the various Loudspeaker locations by playing music with continuous bass, setting up the speakers and listening to them from the main listening spot. Move the Loudspeak- ers to an alternate location and repeat the listening, paying attention to how the bass qualities and response levels change. Do not assume the loudest bass is best; rather listen for booming (a lack of articulation), as well as a balance over the whole spectrum, to assure the bass will not drown out the other parts of the music. Experiment with various Loudspeaker positions until the locations that sound best are found. The XRT2K Midrange/High Frequency Columns Smooth Frequency Response may be altered by large ob- ject(s) located in the sound waves path or by locating the column too close to a side wall. There should be an unob- structed area in front of the column of at least 60 degrees either side from the center axis for the best performance. Refer to figure 9. Locating Loudspeakers for use in Home Theater In a Home Theater application, the placement of Left and Right Front Loudspeakers can be limited by such considerations as the size and location of the video monitor. The locating suggestions in the for use in a Music System section below can still be helpful as a starting place. Refer to figure 10. Locating Loudspeakers for use in a Music System When used in a Music System the distance between the Loudspeakers and the listener to the Loudspeakers should form a equilateral to an acute isosceles triangle. If the speakers are too far apart relative to the listener, some imaging can be lost. Refer to figure 11. Figure 9 Figure 10 Figure 11
