McIntosh XR 27 Owners Manual
This is the 16 pages manual for McIntosh XR 27 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from McIntosh XR 27 Owners Manual (Ocr-read)
Page 1
2 IMPOR T ANT SAFETY INSTRUCTIONS! PLEASE READ THEM BEFORE OPERATING THIS EQUIPMENT.WARNING - TO REDUCE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. General: 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Warning: To reduce risk of fire or electrical shock, do not expose this equipment to rain or moisture. This unit is capable of producing high sound pres- sure levels. Continued exposure to high sound pres- sure levels can cause permanent hearing impair- ment or loss. User caution is advised and ear pro- tection is recommended when playing at high vol- umes. 6. Only use attachments/accessories specified by the manufacturer. Installation: 7. Install in accordance with the manufacturers instruc- tions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other equipment (including amplifiers) that produce heat. 9. Do not use this equipment near water. 10. Do not expose this equipment to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the equipment. 11. Use only with the cart, stand, tripod, bracket, or table specified by the manufac- turer, or sold with the equipment. When a cart is used, use caution when moving the cart/equipment combination to avoid in- jury from tip-over. Care of Equipment: 12. Clean only with a dry cloth. 13. Do not permit objects or liquids of any kind to be pushed, spilled and/or fall into the equipment through enclosure openings. Repair of Equipment: 14. Refer all servicing to qualified service personnel. Ser- vicing is required when the equipment has been dam- aged in any way, liquid has been spilled or objects have fallen into the equipment, the equipment has been ex- posed to rain or moisture, does not operate normally, or has been dropped. 15. Do not attempt to service beyond that described in the operating instructions. All other service should be re- ferred to qualified service personnel. 16. When replacement parts are required, be sure the ser- vice technician has used replacement parts specified by McIntosh or have the same characteristics as the origi- nal part. Unauthorized substitutions may result in fire, electric shock, or other hazards. 17. Upon completion of any service or repairs to this prod- uct, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
Page 2
3 Customer Service Technical Assistance Please Take A Moment Thank You Copyright 2003 by McIntosh Laboratory, Inc. The serial number, purchase date and McIntosh Dealer name are important to you for possible insurance claim or future service. The spaces below have been provided for you to record that information: Your decision to own this McIntosh XR27 Loudspeaker System ranks you at the very top among discriminating music listeners. You now have The Best. The McIntosh dedication to Quality, is assurance that you will receive many years of musical enjoyment from this unit. Please take a short time to read the information in this manual. We want you to be as familiar as possible with all the features and functions of your new McIntosh. Serial Number: Purchase Date: Dealer Name: If it is determined that your McIntosh product is in need of repair, you can return it to your Dealer. You can also return it to the McIntosh Laboratory Service Department. For as- sistance on factory repair return procedure, contact the McIntosh Service Department at: McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-3515 Fax: 607-723-1917 If at any time you have questions about your McIntosh product, contact your McIntosh Dealer who is familiar with your McIntosh equipment and any other brands that may be part of your system. If you or your Dealer wish ad- ditional help concerning a suspected problem, you can re- ceive technical assistance for all McIntosh products at: McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-1545 Fax: 607-723-3636 Safety Instructions ............................................................. 2 Thank You and Please Take a Moment ............................. 3 Technical Assistance and Customer Service ..................... 3 Table of Contents and Important Information ................... 3 Introduction .................... ................................................... 4 Performance Features ........................................................ 5 Dimensions ........................................................................\ 6 Installation ....................................................................... 10 How to Connect using a single amplifier ........................ 12 How to Connect using two amplifiers ............................. 14 How to Connect using three amplifiers ........................... 16 Specifications .................................................................. 18 Packing Instruction .......................................................... 19 Table of Contents Important Information Caution: The XR27 weight is 84 pounds (38kg) and requires two or more persons to safely handle. 1. Loudspeaker Cables of adequate size are important to ensure that there will be no significant power loss or heating. Cable size is specified in Gauge numbers or AWG (American Wire Gauge). The smaller the Gauge number, the larger the wire size: If the Loudspeaker Cables are 25 feet (7.62m) or less, use at least 18 Gauge (AWG) wire size or larger. If the Loudspeaker Cables are 50 feet (38.1m) or less, use at least 14 Gauge (AWG) wire size or larger. If the Loudspeaker Cables are 100 feet (76.2m) or less, use at least 12 Gauge (AWG) wire size or larger. The Loudspeaker Connection Terminals can accept up to 12 Gauge (AWG) wire. 2. For additional connection information, refer to the owner smanual(s) for any component(s) connected to the XR27 Loudspeaker System. 3. The XR27 has built in speaker protection in the form of four automatic resetting solid state devices as part of the crossover networks. One protects the tweeters, one for the midranges and two for the woofers. The characteristics of this protection are that a certain amount of overdrive is allowed but extended periods of overdrive will trigger protection. If an obvious lack of high, mid or low frequencies is noticed, the Loudspeaker Protection Device may have activated. The protection devices will automatically reset when the volume control is reduced significantly and kept low until the output of the affected Loudspeaker Element returns to normal. 4. When the XR27 Loudspeaker System is driven by more than one amplifier, the output levels of the different amplifiers connected to the Loudspeaker System must be adjusted to achieve a proper balance between the low, midrange and high frequencies reproduced. This adjustment is best achieved through the use of audio test equipment operated by a qualified installer. 5. The XR27 is designed to be used with a Subwoofer, like a McIntosh PS112, in order to hear the entire audible range of sound.
Page 6
7 Installation The XR27 Loudspeaker System requires two or more per- sons to safely handle during assembly and placement. Fol- low the instructions below for unpacking and assembly. It is recommended that the Professionals at your McIntosh Dealer, who are skilled in all aspects of installation and operation, install the XR27 Loudspeaker System and any associated audio equipment. Unpacking the Loudspeaker System 1. Remove the banding material from the shipping car- ton. Refer to figure 8. 2. Lift off the top of the shipping carton and set it aside. 3. Lift up on the rear of the Loudspeaker System, near the foam packing material at both ends. Place the entire assembly (Loudspeaker System, Loud- speaker Grille, On-Wall mounting brackets and foam packing material) next to the bottom shipping carton on a flat surface. Refer to figure 9. 4. Release the Loud- speaker Grille from the packing material by opening the slit in the packing material located on the top center. Remove the Loudspeaker Grille from the protective shipping wrap and set it aside. 5. In a similar manner, lift out the Loudspeaker System and set it aside. 6. Replace the shipping carton top onto the shipping car- ton bottom. Take the two center pieces of the just re- moved packing material and lay it down flat onto the top of the shipping carton. 7. Carefully remove the protective shipping bag(s) from the Loudspeaker System so as not to mar the finish or damage the Loudspeaker System Drivers. 8. Place the Loudspeaker System, with the front facing down, on top of the packing material located on top of the shipping carton. Refer to figure 10.Installation Methods The XR27 may be installed using one of five installation methods listed below: 1. Placing the XR27 horizontally on a flat surface using the attached Stabilizer Bar. 2. Mounting the XR27 vertically on a wall using the sup- plied Brackets and Hardware. 3. Mounting the XR27 horizontally on a wall using the supplied Bracket and Hardware. 4. Mounting the XR27 vertically or horizontally In-Wall using the optional McIntosh CK27 which includes Brackets, Hardware and a special Loudspeaker Grille. 5. Using the optional McIntosh ST27 Vertical Mount Floor Stand. Proceed to the desired Installation Method that follows. Installation using the Stabilizer Bar 1. Attach the rubber bumpers to the bottom long edge of the XR27 Loudspeaker System and Stabilizer Bar. Re- fer to figure 11. 2. Loosen, but do not remove, the four screws securing the Stabilizer Bar to the back of the XR27 Loud- speaker System. Refer to figure 11. 3. Reposition the Stabilizer Bar with the widest side even with the long side edge of the XR27 ex- truded aluminum enclosure. Refer to figure 12. 4. Tighten the four screws securing the Stabi- lizer Bar to keep it in place, but not enough to prevent changing the angle of the XR27 in the following steps. 5. The vertical angle of the XR27 may be changed ±5.5 degrees from perpendicular, allowing the sound to be directed upwards or downwards to accom- modate the seating arrangement in the room. Refer to figure 13. This can be accomplished by tempo- rarily loosening the four screws and moving the Stabilizer Bar up or Figure 8 Figure 9 Dimensions and Installation Figure 10 Packing material Figure 13 Figure 12 Stabilizer Bar Screws Stabilizer Bar Large Rubber Bumpers Figure 11 Small Rubber Bumpers
Page 14
15 Packing Instructions In the event it is necessary to repack the equipment for shipment, the equipment must be packed exactly as re- ceived. Failure to do so will result in shipping damage. Use the original shipping carton and interior parts only if they are in good serviceable condition. If a shipping car- ton or any of the interior part(s) are needed, please call or write Customer Service Department of McIntosh Labora- tory. Packing Instructions High Frequency Section Column Quantity Part Number Description 1 034221 Top shipping carton 1 034222 Bottom shipping carton 2 034205 Foam end cap 2 034206 Foam center cap
