McIntosh MX 120 Owners Manual
This is the 52 pages manual for McIntosh MX 120 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from McIntosh MX 120 Owners Manual (Ocr-read)
Page 1
2 IMPOR T ANT SAFETY INSTRUCTIONS! PLEASE READ THEM BEFORE OPERATING THIS EQUIPMENT. WARNING - TO REDUCE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. The lightning flash with arrowhead, within an equilateral triangle, is in- tended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. To prevent the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. The exclamation point within an equilateral triangle is intended to alert the user to the presence of im- portant operating and maintenance (servicing) instructions in the litera- ture accompanying the appliance. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturers instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. Do not expose this equipment to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the equipment. 16. To completely disconnect this equipment from the a.c. mains, disconnect the power supply cord plug from the a.c. receptacle. 17. The mains plug of the power supply cord shall remain readily operable. 18. Do not expose batteries to excessive heat such as sunshine, fire or the like.
Page 2
3 Safety Instructions ............................................................. 2 Thank You and Please Take a Moment .............................. 3 Technical Assistance and Customer Service ...................... 3 Table of Contents ............................................................... 3 Important Information........................................................ 4 Connector Information....................................................... 5 Introduction........................................................................ 6 Performance Features ........................................................ 6 Dimensions......................................................................... 7 Installation......................................................................... 8 Connections Rear Panel Multizone, Control and Switch ........................ 9 Rear Panel Analog and Digital Audio Connections .......... 10 Rear Panel Video Connections ......................................... 11 How to Connect Multizone, Data and Power Control ..... 12 How to Connect Digital Audio Components .................... 13 How to Connect Analog Audio Components for eight channels ............................................................. 14 How to Connect Analog Audio Components for five or six channels ..................................................... 16 How to Connect Video Components ................................ 17 How to Connect for Zone B ............................................. 18 Front Panel Features Front Panel Controls and Sensor ..................................... 19 Front Panel Push-button and Switch ................................ 20 Front Panel Displays ........................................................ 21 Remote Control Remote Control Push-Buttons.......................................... 22 How to Operate by Remote Control ................................. 23 Setup Mode How to Operate the Setup Mode ...................................... 24 Default Settings ................................................................ 25 How to Adjust for Loudspeaker Size ............................... 26 How to Adjust Loudspeaker Time Delay ......................... 28 How to Adjust Loudspeaker Levels ................................. 29 How to Change the Input Setup ....................................... 31 How to Change the Volume Setup .................................... 37 How to Change the Advanced Settings ............................ 38 Operation How to Operate the MX120 ............................................. 40 How to Operate the Trim Mode ....................................... 43 How to Operate the Surround Mode ................................ 46 How to Make a Recording ............................................... 48 How to Operate Zone B ................................................... 49 Additional Information Specifications................................................................... 50 Packing Instructions ......................................................... 51 Table of Contents Your decision to own this McIntosh MX120 A/V Control Center ranks you at the very top among discriminating mu- sic listeners. You now have The Best. The McIntosh dedi- cation to Quality, is assurance that you will receive many years of musical enjoyment from this unit. Please take a short time to read the information in this manual. We want you to be as familiar as possible with all the features and functions of your new McIntosh. Customer Service Technical Assistance Please Take A Moment Thank You Copyright 2007 © by McIntosh Laboratory, Inc. The serial number, purchase date and McIntosh Dealer name are important to you for possible insurance claim or future service. The spaces below have been provided for you to record that information: Serial Number: Purchase Date: Dealer Name: If it is determined that your McIntosh product is in need of repair, you can return it to your Dealer. You can also return it to the McIntosh Laboratory Service Department. For as- sistance on factory repair return procedure, contact the McIntosh Service Department at: McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-3515 Fax: 607-723-1917 If at any time you have questions about your McIntosh product, contact your McIntosh Dealer who is familiar with your McIntosh equipment and any other brands that may be part of your system. If you or your Dealer wish additional help concerning a suspected problem, you can receive tech- nical assistance for all McIntosh products at: McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903 Phone: 607-723-1545 Fax: 607-723-3636
