McIntosh MR 80 Owners Manual
This is the 22 pages manual for McIntosh MR 80 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from McIntosh MR 80 Owners Manual (Ocr-read)
Page 1
VARIOUS REGULATORY AGENCIES REQUIRE THAT WE BRING THE FOLLOWING INFORMATION TO YOUR ATTENTION. PLEASE READ IT CAREFULLY. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. The Mclntosh you have purchased is a Model MR 80. It has a serial number located on the rear panel of the chassis. Record that serial number here: Serial Number The model, serial number and purchase date are important to you for any future service. Record the purchase date here: Purchase date Upon application, Mclntosh Laboratory provides a Three-Year Service Contract. Your Mclntosh author- ized service agency can expedite repairs when you provide the Service Contract with the instrument for repair. To assist, record your Service Contract number here: Service Contract Number
Page 2
Your MR 80 Digital FM Tuner can give you many years of satisfactory performance. If you have any questions, please contact: CUSTOMER SERVICE Mclntosh Laboratory Inc. 2 Chambers Street Binghamton, New York 13903-9990 Phone: 607-723-3512 Take Advantage of 3 years of Contract Service ... Fill in the Application NOW. Contents SERVICE CONTRACT INFORMATION . . . 1 INSTALLATION ..2 HOW TO CONNECT AND BACK PANEL INFORMATION...4 FRONT PANEL INFORMATION AND USE OF CONTROLS. . .6 TOP PANEL INFORMATION AND SECONDARY CONTROLS . . .8 PERFORMANCE LIMITS . . .9 PERFORMANCE CHARTS. -10 TECHNICAL DESCRIPTION. 14 BLOCK DIAGRAM..20 MclNTOSH THREE YEAR SERVICE CONTRACT An application for A THREE YEAR SERVICE CONTRACT is included with this manual. The terms of the contract are: 1. Mclntosh will provide all parts, materials and labor needed to return the measured performance of the instrument to the original performance limits. The SER- VICE CONTRACT does not cover any shipping costs to and from the authoriz- ed service agency or the factory. 2. Any Mclntosh authorized service agency will repair Mclntosh instruments at nor- mal service rates. To receive service under the terms of the SERVICE CON- TRACT, the SERVICE CONTRACT CER- TIFICATE must be presented when the instrument is taken to the service agency. 3. Always have service done by a Mclntosh authorized service agency. If the instrument is modified or damaged as a result of unauthorized repair, the SERVICE CONTRACT will be cancelled. Damage by improper use or mishandl- ing is not covered by the SERVICE CONTRACT. 4. The SERVICE CONTRACT is issued to you as the original purchaser. To pro- tect you from misrepresentation, this contract cannot be transferred to a se- cond owner. 5. To receive the SERVICE CONTRACT, your purchase must be made from a Mclntosh franchised dealer. 6. Your completely filled in application for the SERVICE CONTRACT must be post- marked within 30 days of the date of purchase of the instrument. 7. To receive the SERVICE CONTRACT, all information on the application must be filled in. The SERVICE CONTRACT will be issued when the completely filled in application is received by Mclntosh Laboratory Incorporated in Binghamton, New York. 8. Units in operation outside the United States and Canada are not covered by the Mclntosh Factory Service Contract, irrespective of the place of purchase. Nor are units acquired outside the U.S.A. and Canada, the purchasers of which should consult with their dealer to ascertain what, if any, service con- tract or warranty may be available locally. Copyright 1980 © by Mclntosh Laboratory Inc. 1
Page 4
FM CABLE INPUT OR 2ND 75W ANTENNA LEAD-IN FM ANTENNA OPTIONAL 75W ANTENNA LEAD-IN REMOTE CONTROL PUSH BUTTON POWER AMPLIFIER PREAMPLIFIER LEFT SPEAKER RIGHT SPEAKER 5 MAXIMUM PERFORMANCE INDICATOR OR OSCILLOSCOPE TO AC POWER SOURCE
