McIntosh MDA 1000 Brochure

Page 1

For the Consumers Protection: In order to ensure the highest level of customer satisfaction, newMcIntosh products may only be purchased over-the-counter or delivered and installed by an Authorized McIntosh Dealer. McIntosh products that are purchased over the Internet, by phone or mail order are presumed to be usedand do not qualify for any McIntosh Warranty. McIntosh does not warrant, in any way, products that are purchased from anyone who is not an Authorized Dealer or products that have had their serial number altered or defaced. 11.04.MDA1000.20K 35006500 McIntosh Laboratory, Inc. 2 Chambers Street, Binghamton, New York 13903-2699 Tel (607) 723-3512 - US Toll-Free (800) 538-6576 - Fax: (607) 724-0549 - www.mcintoshlabs.com MDA1000 D/A Converter POWER SUPPLY Multiple layers of regulation provide clean power to all critical circuits. The power transformer has the lowest noise field of any available. CIRCUIT SHIELDS Each D to A Converter is shielded to avoid any chance of hum or noise getting through. VOLUME CONTROL Precision front panel and remote volume control allow the MDA1000 to function as a preamplifier in an all-digital system. Setup programming allows volume control bypass if desired. FRONT PANEL DESIGN 3D front panel glass design is illuminated with long-life, cool-running fiber optics that make operation in low light easier. Silk screening on the inside of the glass front panel prevents wear of the nomenclature, ensuring lasting beauty and highest resale value…a McIntosh hallmark feature. ANALOG AUDIO FREQUENCY RESPONSE: ±0.5dB from 4Hz to 45kHz (sampling frequency 96kHz and 88.2kHz) ±0.3dB from 4Hz to 22kHz (sampling frequency 48kHz) ±0.3dB from 4Hz to 20kHz (sampling frequency 44.1kHz) ±0.3dB from 4Hz to 15kHz (sampling frequency 32kHz) TOTAL HARMONIC DISTORTION0.002% at 1kHz A-WEIGHTED SIGNAL-TO-NOISE RATIOBetter than 110dB DYNAMIC RANGE:Better than 100dB (1kHz) RATED OUTPUT VOLTAGE:2V Unbalanced Outputs (BYPASS ON Mode) 6V Unbalanced Outputs (BYPASS OFF Mode) 2V Balanced Outputs (BYPASS ON Mode) 6V Balanced Outputs (BYPASS OFF Mode) DIGITAL AUDIO SPECIFICATIONS DIGITAL AUDIO FORMAT IEC958, S/PDIF COAXIAL INPUTS (1, 2, AND 3)0.5V p-p @ 75 ohms OPTICAL INPUTS (4, 5, AND 6)-15 ~ 20dBm XRL INPUT (7)5V p-p @110 ohms SAMPLING FREQUENCIES:96kHz, 48kHz, 44.1kHz and 32kHz POWER REQUIREMENTS:100 Volts, 50/60Hz, 20W 110 Volts, 50/60Hz, 20W 120 Volts, 50/60Hz, 20W 220 Volts, 50/60Hz, 20W 230 Volts, 50/60Hz, 20W 240 Volts, 50/60Hz, 20W OVERALL DIMENSIONS (H x W x D including knobs and feet) 6" (15.2cm) x 17-1/2" (44.5cm) x 16-1/8" (41cm) WEIGHT:24 lbs. (11kg) net, 38 lbs. (17kg) boxed The unique design of the MDA1000 top cover is machined from thick aluminum panels with a smooth black anodized finish. It contains a recessed area of glass on which is screened the block diagram of the MDA1000s circuitry and a recessed logo in McIntoshs signature gold.
