For the Consumers Protection: In order to ensure the highest level of customer satisfaction, newMcIntosh products may only be purchased over-the-counter or delivered and installed by an Authorized McIntosh Dealer. McIntosh products that are purchased over the Internet, by phone or mail order are presumed to be usedand do not qualify for any McIntosh Warranty. McIntosh does not warrant, in any way, products that are purchased from anyone who is not an Authorized Dealer or products that have had their serial number altered or defaced. 11.04.MCD1000.20K 35006400 McIntosh Laboratory, Inc. 2 Chambers Street, Binghamton, New York 13903-2699 Tel (607) 723-3512 - US Toll-Free (800) 538-6576 - Fax: (607) 724-0549 - www.mcintoshlabs.com MCD1000 CD Transport POWER SUPPLY Multiple layers of regulation provide clean power to all critical circuits. The R-Core power transformer has the lowest noise field of any available. TRANSPORT ISOLATION High power systems with high power woofer systems place greater demands on the CD transport. The MCD1000 is designed to work under these conditions without producing tracking error that must be corrected later down the data stream. MACHINED TOP AND SIDE PANELS The top and sides of the MCD1000 are machined from thick aluminum panels with a smooth black anodized finish. In the recessed area of the top panel is a glass panel screened with a block diagram of the MCD1000s circuitry. FRONT PANEL DESIGN 3D front panel glass design is illuminated with long-life, cool-running fiber optics that make operation in low light easier. Silk screening on the inside of the glass front panel prevents wear of the nomenclature, ensuring lasting beauty and highest resale value …a McIntosh hallmark DIGITAL AUDIO FORMATIEC958, S/PDIF DIGITAL OUTPUTSOptical: -15 ~ -20dBm Coaxial: 0.5V p-p @ 75 ohms XRL: 5V p-p @ 110 ohms (AES/EBU) TRANSPORT:Pickup: Optical 3-beam laser Objective Lens Drive System: 2-dimensional parallel Laser Type: GaAIAs Semiconductor Laser Beam Wavelength: 780nm DIGITAL SIGNAL FORMAT:Sampling Frequency: 44.1kHz Quantization Bit: 16-bit linear/channel Modulation Code: Eight to fourteen modulation Error correction: Cross Interleave Reed Solomon POWER REQUIREMENTS:100 Volts, 50/60Hz, 20W 110 Volts, 50/60Hz, 20W 120 Volts, 50/60Hz, 20W 220 Volts, 50/60Hz, 20W 230 Volts, 50/60Hz, 20W 240 Volts, 50/60Hz, 20W OVERALL DIMENSIONS (H x W x D including knobs and feet) 6" (15.2cm) x 17-1/2" (44.5cm) x 16-1/8" (41cm) WEIGHT:27-1/2 lbs. (12.5kg) net, 41-1/2 lbs. (19kg) boxed The unique design of the MCD1000 top cover is machined from thick aluminum panels with a smooth black anodized finish. It contains a recessed area of glass on which is screened the block diagram of the MCD1000s circuitry and a recessed logo in McIntoshs signature gold.
