Page 1
MA6600 Integrated Amplifier Output and Loudspeaker Connection Diagram 1 B Note: Refer to the MA6600 Owners Manual page 9 for additional connection information. Connection Legend: Data Cable*- Digital Signal Cable - Sensor/Keypad Cable - RS232 Cable - Power Control Cable* - Ground Wire - Audio Signal Cable - AC Power Cords - Video Signal Cable - Loudspeaker Cable - RF Signal Cable - * 2 conductor shielded with 1/8 inch stereo mini phone plug on each end. Connect to AC Outlet McIntosh Power Amplifier - Secondary Room (Partial View) Connect to AC Outlet + - + - + - +-
