Why, since its beginning in 1949, has Mc- Intosh been acknowledged as the worldwide leader for good sound, realistic music re- production, the chief source for technologi- cal advancement, outstanding appearance, quality, and value? Why has the industry used "as good as a McIntosh" as its yardstick by which to compare. McIntosh has care- fully and expertly merged the many contributing elements into a result that is universally envied and copied but never equaled! The C 33 Control Center is the latest illustration of some of the factors contributing to the McIntosh reputation. McIntosh unites: - continued research into user desires consistent with high quality music reproduction, - engineering that is aggressively inquisitive in the search for better ways to bring these user dictated requirements to a technologically superior, innovative and clearly useful result, - appearance design that has long life, complements the living style, is complimentary to the owner, and is made of materials, whose characteristics permit'a like new always' appearance, - easy to operate; The unique McIntosh designed panels are always easily readable in your choice of home lighting They are obviously designed by human beings for human beings. - manufactured of carefully specified and selected compo- nent parts that have high quality and long predicted life, - assembled by highly trained craftspeople who are dedicated to quality, accuracy and perfection, - thorough verification of the desired capabilities and quality of performance by constant and complete testing throughout the entire manufacturing process. These are some of the elements that are positive and readily verifiable. There are other elements in the McIntosh reputation that are less tangible, but no less important. McIntosh has never dissipated resources on opportunistic adventures into pure commercialism like quadraphonic sound. Today many people are mountain climbing on mole hills in their effort to find some point to extol their products. They would have you worry about: - distortion in soldered joints, distortion in capacitors, speaker cones not made with Mt. Fuji water, conducting electrical sound frequencies in anything but litz wire, transient inteimodulation distortion and many other scientifically indefensible allegations. The reproduction of sound is a very complex undertaking when you live merely with reality. There is no need to complicate reality and waste time and energy with incantations over a witch's brew of speaker wires, toroids, classes A thru Z, direct coupling, DAD, no IC's etc. etc.
