Marantz SR 9200 Service Bulletin 2
This is the 5 pages manual for Marantz SR 9200 Service Bulletin 2.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Marantz SR 9200 Service Bulletin 2 (Ocr-read)
Page 1
Approved by H.TAMURAWritten by K.ONOWQ-19 2 817/additional rule3 (1st Issue 2003-03-19)Date :15-May-2003 Model SR9200/SR8200 Page :1/1 REF.NBR :MZ03-010 Circulation:Application: Subject: Int.ref :[ PHENOMENON] 1. Sound cut a little at the beginning of the track with digital connection and with CD or DVD playback. It will happen with first playback and after track skip. 2. Volume level will decrease a little when changed from Digital input (as CD input) to Analog input (as Tape input) , and vice versa. It happens only the Bass/Treble control is set to other than default 0 setting. [SOLUTION] Update the firmware for CPU and DSP. Firmware for CPU : SR9200UP_NEW_DSP_030124 Firmware for DSP : SR9200UP_NEW_H8_0130_1 (Unzip the file distributed before update.) Please refer to the SR9200/SR8200 Service manual page 87 9.UPDATE FIRMWARE about details of updating the firmware. [REMARKS] After update the unit, following surround mode will be changed. (Caused by new DSP firmware.) So, please explain to your customer this change. * SR9200 1. THX Ultra mode => THX Ultra2 mode 2. SRS CS => SRS CS II * SR8200 1. SRS CS => SRS CS II This countermeasure only applies to this claim. SERVICE BULLETINSound cut a little at the beginning of the track Volume level will decrease when changed Digital and Analog input xfor information customer complaint in case of service mandatory ...................ALL
Page 2
Approved by H.TAMURAWritten by K.ONO WQ-19 2 817 /additional rule3 (1st Issue 2003-03-19) Date: 15-May-2003Model SR8200,SR9200 Page: 1/1REF.NBR: MZ02-040 Circulation:Application: Subject: Int.ref: [ PHENOMENON] When Push the power switch On/Off, VOL Level and Tune preset memory aren't Back up. The leakage current of the condenser occurs at low temperature, and it isn't suitable for the timing in Power off. [SOLUTION] Replace C801 (0.01uF) to 0.0047uF (Parts No. DK17472910 ) on the P824 POWER SW CIRCUIT BOARD. [REMARKS] This improvement has been done in the production after the Lot number below. SR8200 Lot number 08 and after. SR9200 Lot number 09 and after. The Lot number is mentioned the serial number label on the rear panel. (ex.MZxxxxxx08xxxx ) SERVICE BULLETIN VOL Level and Tune preset memory aren't Back up. x for information customer complaint in case of service mandatory ................... Before
