Marantz SR 5000 OSE Service Manual
This is the 1 pages manual for Marantz SR 5000 OSE Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Marantz SR 5000 OSE Service Manual (Ocr-read)
Page 1
serVi ce SR5000F/NzB/T23
Manual AV Surround receiver
::: WWI-(Wigfis E;
REMARK : This service manual explains the electrical differences between the
SR5000/N1 B/T1 B (SRSOOO) and the SRSOOOF/NZB/TZB (SR5000 OSE).
All other information is described in the service manual of the model SR5000
/NtB/TtB (Code number :3120 785 22170 / 285W855010). The dispatch of
the parts for after sales service has to be referred to these service manuals,
with the first priority. For this reason, please use these service manuals with
referring to the models SR5000/N1 B/T1 B service manual without fail.
The SR5000 OSE is equal to the SR5000 except the following electrical
changes (mechanical changes are not listed):
Position No. PART NO. (PCS) Description PART NO. (MJI)
nsp OSE Badge nsp
3 9965 000 09311 Knob Volume (Metal) 313W154500
C935 9965 000 09312 ELECT 18000 F 71V OB18907110
C936 9965 000 09312 ELECT 18000 F 71V 0318907110
Please use this service manual with referring to the user guide (D.F.U) without fail.
maranll®
Printed in The Netherlands
SR5000 OSE
285W855040 SIG
3120 785 22650
First lssue:2001.05
