Marantz SD 5 Service Manual
This is the 4 pages manual for Marantz SD 5 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Marantz SD 5 Service Manual (Ocr-read)
Page 1
Techmcal. 7 L
Services 1
Page 2
Specifications. ..
Impedance: 8 ohms @ 1kHz
Sound Pressure Level: 100 dB SPL @ 1kHz 7
Maximum Sound Pressure Level: 0.15 volts RMS input
Frequency Range: 30Hz to 15kHz
Total Harmonic Distortion (THD): 1.0 % @ 30Hz (100 dB SPL)
0.18% @1kHz (100 dB SPL)
0.25% @10kHz (100 dB SPL)
Sensitivity: 0.15 volts RMS for 100 dB SPL
Weight: 16 oz.
Parts Ordering:
Repiacement parts for the SD?) Headphones may be ordered from:
Marantz Parts Department
8144 Sunland Boulevard
Sun Valley, CA 91352
When ordering, use the exact parts description and number indicated in Figure 2.
schematic
RED +
.-
-.-
BLK -
BLK
-.
P1 I
RED
0
WHT
WHT +
BLK -
Figure 1
LS1
Rt Ch
Headphone
L32
Lt Ch
Head phone
