Far more than massive current capability elegantly housed in brushed aluminum, the MA-9S2 thoroughly updates the performance of our original Model 9. Its the culmination of more than a half-centurys efort in reproducing audio in the home. Of course, this must be a Marantz. A major untertaking, the engineers at Marantz tore apart the MA-9S1 and redesigned it from the ground up to be even faster, with less noise, and more authority. The MA-9S2 represents over 50 years of expertise in amplifer circuitry, and sincere love of music. - 300 Watts into 8 Ohms, 600 Watts into 4 Ohms - >150 Amps Peak Current Supply - Custom HDAM® SA Modules - Full Current Feedback Amplifer Stage - Double Shielded Low noise Toroidal Transformer - Fully Balanced Amplifer Design - Choke Input System Power Supply - Custom Extruded Aluminum Heat Sink - Heavy Gauge Internal Wiring - All Copper Plated Chassis and Double Layered Bottom Plate - Dual WBT® Speaker Outputs MA-9S2 Reference Monoblock Amplifer *All specifcations, dimensions and weights are subject to change without notice. D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors in this spec sheet which may result in consequential errors being made by retail dealers, designers, custom installers, cabinet makers or end users, etc based upon information contained within this document. ©2007 Marantz America, Inc. - www.us.marantz.com FEATURESNumber of Channels Output Power/Channel (20Hz - 20kHz) @ 8 Power Transformer Discrete Amplifer Stage Individual Level Adjust IN/OUTPUTSAUDIO Analog L&R In Main Channel Amp In Bridge Mono Mode Analog L&R Out Headphone Out OTHERS D-Bus Remote (RC-5) In/Out External Control SPECIFICATIONS THD (20Hz - 20kHz, 8 Input Sensitivity/Impedance Frequency Response S/N Ratio GENERALColor Front Panel Remote Control Power Requirement Power Consumption Dimensions (Inches) W x H x D Weight (lbs.) 1 300W Toroidal - - - 1/1 (Balanced Mono/Unbalanced Mono) - - - - - 0.01% 1.7V/20k 3Hz - 120kHz (+0, -3dB) 120dB Gold Aluminum AC 120V 60Hz 500W 18 1/16" x 7 13/16" x 17 3/4" 78.9-
