Marantz LC 2601 Owners Manual
This is the 47 pages manual for Marantz LC 2601 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Marantz LC 2601 Owners Manual (Ocr-read)
Page 1
1 General Information ENGLISH Image Retention Effect (Image Sticking) 1. Cause : - Image Retention Effect may come from displaying a still picture in a certain period of time with at a certain area continuously, as feature of LCD panel. This is caused due to brightness degradation. Many LCD manufacturers are trying to overcome this limitation. 2. Prevention - To avoid this matter, use the product after reducing brightness and contrast, especially when a still image is displayed for a long time. (Contrast 50/Brightness 50 - See 18 page) Once an image retention occurs, use the mode that displays motion. It will reduce this matter. 3. Solution - The temporary image sticking would decrease with displaying Full-White pattern during 10 hours. * The permanent image sticking could not take off under the latest technology. This method may be used to eliminate a temporary retained image that occurs after displaying a still image in a certain period of time. Since it may take several minutes to several hours to remove image sticking, it is recommendable to display motion pictures during 2~3 minutes every hour when keeping displaying a still image. As image sticking is influenced by the brightness of a still image being displayed and its display time, it is recommended to reduce the brightness of the screen. * Image Sticking does not come under the warranty. When watching a still Image within motion pictures and Wide/Zoom1/Zoom2 /14:9/4:3 screen 1. Note : - When the central area of the screen and the screen edges are fixed, the different brightness level of the edges may cause image retentions on the edges when watching for a long time - This phenomenon happens also to products from other manufacturers. Please avoid to watch a still image for a long time. - If you watch a still image for a long time, this may damage your TV. * This matter does not come under the warranty. Wide,Zoom1, Zoom2, 14:9, 4:3 screen Box still image Important Tip Image Sticking Precaution
Page 2
2 General Information ENGLISH Safety Precaution The contents of this section are provided for the safety of users and their property. Please read the instructions carefully before using. Do not connect multiple electrical appliances to a single outlet. - It may cause a fire due to overheating from the outlet. Outdoor Antenna Grounding If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No.70-1984, provides information about proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. Example of Grounding According to National Electrical Code Instruction Do not use or store a flammable spray or inflammable things near the TV. - They may cause explosion or fire. Do not install the TV in a bookshelf, closet, or a place with poor air circulation. - Fire may be caused due to the rise of internal temperature. Make sure to remove the speakers before moving the TV with speakers mounted on it. - When the speakers are detached from the unit while carrying it, this may cause damage to the unit or personal injury. Any necessary action such as making the antenna cable loop at the entrance of the building should be taken to prevent rainwater on the outdoor antenna cable from possibly running indoor. - If raindrop gets into the LCD TV, it may cause a fire or an electric shock.
