Page 1
Approved by H.TAMURAWritten by K.ONOWQ-19 2 817/additional rule3 (1st Issue 2003-03-19)Date :15-May-2003 ModelDV4200/DV6200
Page :1/1 REF.NBR :MZ02-025
Circulation:Application:
Subject:
Int.ref :[ PHENOMENON]
1) Sound skips and picture freeze 1 second at the chapter 8 with DVD disc Beauty and Beast.
2) Subtitle will be ON automatically at the chapter 3 with DVD disc SPY GAME.
3) Subtitle will be ON automatically at the 1700 with DVD disc The World is not Enough.
[SOLUTION]
Update the firmware version to [Ver.2.21MP].
The way of firmware version up is as follows;
Connect the DVD player to [ TV ] and operate by using [ Remote Controller ]
1) Insert the update disc (Part No. *DV4200CD3) into the product.
2) FLD indicates [ PrESS UP ] when the disc is detected.
3) Press
(up) button.
4) FLD indicates [ rEAd 0 ]. If FLD indicated [ rEAd 1 ] or other number, please refer to the following .
5) FLD indicates [ UPgrAdE 0 ]. After few minutes, FLD indicate [ FInISHEd ] and the tray will be opened automatically.
6) Remove the disc. Press OPEN/CLOSE button and the power will be turned off automatically.
7) The product should be confirmed the firmware version and be reset.
8) Press POWER button and press SETUP button.
9) Select TV aspect and press
(right) button.
10) Press (up) button or
(down) button and choose 16:9 wide.
Attention : Do not press SELECT/ENTER button ( Keep green triangle mark )
If check mark is appeared, press
(right) button and change to green triangle mark.
11) Enter the code number "1397139" by Numeric buttons.
12) Press SELECT/ENTER button.
The connected TV indicates SYSTEM INFORMATION
Please check MICOM-VER is "2.21MP".
If other number indicate, need to retry this procedure again.
13) Press POWER button and turn off the power.
"Update firmware" and "Reset" are succeeded.
During reading the update disc, error messages are as follows
[Error Num] = 1 ~ 3
You can retry to upgrade by disc.
Because, flash ROM is not erased data yet.
[Error Num] = 4 ~
It is very worst case. The flash ROM is broken during erasing or programming.
You need to rewrite from hardware (PC) for using another jig.
[
REMARK]
This improvement has been done in the production line after the production week code number 0250 and later. The
production week code is mentioned in the serial number label on the rear panel. (ex. MZxx0250xxxxxx)
SERVICE BULLETIN
Improvement for playability of DVD disc Beauty and
Beast and subtitle problem with some disc xfor information
customer complaint
in case of service
mandatory
...................
Before
MZxx0249xxxxxxSYSTEM INFORMATION
MODEL : DVxxxx/xxx
REGION-NO :1
CHIP-ID :PANTERA II
SERVO-VER :b003
MICOM-VER :V2.21 MP
PROM OPTION :XX XX XX XX XX XX
Factory Reset..Done
Example indicated
