Page 1
English 5 COMPACT DISCS The glossy side shining like a rainbow is the front side of the disc, and the side on which the label is printed is the back. Unlike conventional turntables for playing analog discs, the CD6000/ CD6000OSE Compact Disc Player reads the information recorded on the disc from underneath without contacting it using a beam of laser light. Therefore, the performance of a compact disc will not degrade like conventional analog records. Handle discs carefully so as not to damage or scratch the front side. To protect the disc, avoid placing it in the following locations: Ð In direct sunlight or near a source of heat like a heater. Ð In a place which is damp or dirty. Ð In a place which could be exposed to rain, such as near a window. Always keep the disc surface clean. Up to six billion data units are recorded on the front side of the disc. When cleaning the disc surface, always be sure to use a special compact disc cleaner and wipe as shown below. ¥ Do not use conventional record cleaner for analog records, as this will adversely affect the disc surface. Store discs properly by placing them in their disc cases. ¥ Do not attach a piece of paper or sticker on the label side of disc. When a disc has a piece of plastic tape or rental CD label with paste protruded from the edge or when a disc has a trace of such a sticky object, do not attempt to play the disc. If such a disc is played on the CD player, impossibility of taking out the disc or other malfunction may result. ¥ Do not use a disc with a special shape. Do not attempt to play a disc with a special shape such as a heart- shaped disc or octagonal disc. Otherwise the equipment malfunction may result. Wipe in a radial direction. Do not wipe in circumferential direction. About CD-TEXT The CD-TEXT is a new type of music CD featuring the recording of character information on the performer names, album name, track names, etc., in addition to the audio information contained in music CD. The character information is recorded in an area which has not been utilized by previous music CDs. This means that the CD-TEXT discs can be played back in the same way as ordinary music CD discs on any CD player and that a CD-TEXT compatible player such as this unit can view the character information in them as well as the audio. This unit detects the CD-TEXT compatibility of each disc automatically and displays the result in the display panel. By operating the provided remote control unit, the display can show the character information including the album name, track names, per- former names, verse writer names, music composer names, arranger names, message and music genre. However, note that the content of the character information is variable depending on discs. * For detailed operating procedures for displaying the character infor- mation in the CD-TEXT, read the description in the main text of this manual. The display of this unit can display up to 12 characters at a time. If the character information in a disc is longer, the characters are scrolled from the left to the right on the display. * Scrolling refers to a method of displaying characters by moving them. This unit is capable of smooth scrolling by feeding characters bit by bit. Some of the CD-TEXT compatible discs also contains the recording of the highlight sections of its tracks. This unit is capable of playing only the highlight sections one after another, and this feature is referred to as HIGHLIGHT SCAN. Playing CD-RW discs This unit can play back the CD-RW (ReWritable) discs as well as ordinary music CD and CD-R (Recordable) discs. * The CD-R and CD-RW discs should contain properly-recorded TOC information so that they can be played back. With the CD recorder system, writing the TOC information in a disc is referred to as finalizing the disc. A disc cannot be recognized as a CD disc and played back unless it has been finalized properly. For details, please read the instruction manual provided with a CD recorder. * TOC stands for Table Of Contents and contains information such as the total number of tracks and total playing time of the disc. * This unit can play only the discs recorded in the CD-DA format designed for music reproduction. Do not attempt to play a disc containing other data, such as a CD-ROM for PCs, on this unit. * As the playback of a CD-RW disc necessitates partial change of the player setup, it may take longer time for reading the TOC information than when a music CD or CD-R disc is played. TEXT 1 2TTL TTL TIME 34 56 78 91011121314151617181920 Lights up when the loaded disc is CD-TEXT compatible. Main unit display
Page 2
English 6 CONTROLS, CONNECTIONS AND INDICATORS Please read the following instructions referring to the illustration on page 122. FRONT z zz z z POWER switch Press to switch power ON, and press again to switch OFF. x xx x x DISC TRAY Place a disc with the label side up. c cc c c REMOTE SENSOR This window receives signals transmitted from the remote control unit. v vv v v Display Shows information such as the power ON/OFF state, track number, playing time and current operation mode. q qq q q TIME/TEXT information Shows the time information when an ordinary music CD is played, and shows the text information when a CD-TEXT compatible disc is played. w ww w w TEXT (CD-TEXT) indicator Lights up when a CD-TEXT compatible disc is loaded. e ee e e Track number indicator When a disc is placed on the tray and the tray is closed, the TOC* is read and the numbers of all the tracks on the disc are displayed Ò Ó lights up if there are more than 20 tracks on the disc. In program mode only the track numbers of the programmed tracks light up. The track numbers go out in turn as each track finishes playing. * TOC is the discÕs ÒTable Of ContentsÓ and contains non-audio data such as the track numbers and playing times of all the tracks on the disc. r rr r r Output level indicator Shows the analog output level as a relative reference. t tt t t DISC indicator Blinks during TOC readout. y yy y y TTL (Total) indicator Lights up when the total number of tracks in a disc is displayed. u uu u u RNDM (Random) indicator Lights up in the random play mode. i ii i i PROG (Program) indicator Lights up in the programming or delete programming mode. o oo o o TRK (Track) indicator Lights up when the track number being played is displayed. !0 !0!0 !0 !0 EDIT indicator Lights up when the player is in edit mode. !1 !1!1 !1 !1 A-B indicators Both indicators light up in the A-B repeat mode or one of them lights up during playback of tape side A or B in the edit mode. !2 !2!2 !2 !2 INDX (Index) indicator Lights up when the index number being played is displayed. !3 !3!3 !3 !3 RPT (Repeat) indicators RPT: Lights up during all-track repeat mode, which plays all the tracks on the disc repeatedly. Also lights up during program repeat mode, which plays all the programmed tracks repeatedly. RPT 1: Lights up during 1-track repeat mode, which repeatedly plays a single track repeatedly. !4 !4!4 !4 !4 PEAK indicator Lights up during peak search, and flashes during playback of the peak. !5 !5!5 !5 !5 (Pause) indicator Light up in the pause mode. !6 !6!6 !6 !6 TTL (TOTAL) indicator Indicates the remaining playing thme of the entire disc. In program mode, this indicator shows the remaining playing of the current program. !7 !7!7 !7 !7 (Play) indicator Light up during CD playback. !8 !8!8 !8 !8 TIME indicator Lights up in the time display mode. b bb b b PHONES Jack Jack for connecting headphones. n nn n n EDIT button Press to engage the editing function, which helps record a disc onto a tape by playing the tracks according to the tape length and leaving a non-recorded blank of 4 seconds between every track. m mm m m , (Track Previous/Next) buttons When the button is pressed during playback, play re-starts at the beginning of the current or a previous track. When the button is pressed, play re-starts at the beginning of the next or a subsequent track. Hold down or button to find a particular passage in a backward or forward direction. The selected track number is shown on the display. These buttons can also be used to select a desired track from which to start playback. These buttons are also used in program mode to select tracks for programming. , ,, , , STOP button Press to stop playback. This button is also used for deleting a program. . .. . . PAUSE button Press to interrupt playback temporarily. The indicator lights up during pause. When pressed again, the indicator goes out and playback resumes from the same position. Ú0 Ú0Ú0 Ú0 Ú0 PLAY button Press to start playback. Ú1 Ú1Ú1 Ú1 Ú1 PEAK SEARCH button When the PEAK SEARCH button is pressed, searching for the loudest passage (peak) on a CD or in a program. Ú2 Ú2Ú2 Ú2 Ú2 OPEN/CLOSE button Pressing the OPEN/CLOSE button opens the disc tray. Place a compact disc on the tray ith the label side facing up. Gently press the front of the disc tray to close. Ú3 Ú3Ú3 Ú3 Ú3 SCROLL/(RECALL) button Press this button to display the programmed track numbers and program numbers (the order the tracks are programmed) in sequence. If the loaded disc is a CD-TEXT disc, press this button while the text information is displayed to scroll the characters. Ú4 Ú4Ú4 Ú4 Ú4 CD-TEXT. button When playing a CD-TEXT disc, press this button to switch the time display to the text information display. * If this button is pressed when the loaded disc is not a CD-TEXT compatible disc, the display shows "No Text" then returns to the time display. !3 RNDM PROG EDIT A – B RPT 1 DISC TEXT 1 2TTL TRK INDX PEAK TTL TIME 34 56 78 91011121314151617181920 r o t y u i !0 !1 !2 !6 !8 !4 !5 !7 qw e
