Page 1
CONTENTS INTRODUCTION3 MAINS CONNECTIONS4 CONNECTING YOUR PREAMPLIFIER5 FIGURE 1FRONT PANEL6 FIGURE 2REAR PANEL7 OPERATIONAL NOTES8 SPECIFICATIONS9 WARRANTY10 WARRANTY REGISTRATION11 SECTION PAGE
Page 2
INTRODUCTION!THANK YOU!... for choosing the Manley Laboratories CONTROL MASTER Preamplifier. Designed by David Manley, the Mastering Room LINE Preamplifier uses the best available parts with the shortest, cleanest, signal path possible. With the use of our own in-house C.N.C. milling machine, we can provide you with a superb sounding machine with elegant packaging. The design is completely DUAL-MONO with separate power supplies for each channel including two custom designed power transformers. The audio boards are also separate. All the wiring from the rear input connectors to the front selector switch and precision custom stepped attenuator is painstakingly hand wired using professional studio twisted pair shielded six-9's copper cable for optimum shielding and lo-noise characteristics, and although it would be much cheaper, easier, and faster to simply put these leads on several feet of printed circuit board traces like most everybody else does, we opt for purity of sound however many more hours it takes. The high-current line amplifier circuit employed here is one we have developed and refined over the years in our MANLEY Professional series. We hope you agree with us and hundreds of satisfied users and studios around the world that this circuit really delivers. Please take a few moments to read through this manual, there may be features and information about this preamplifier which you should familiarise yourself with. Thank you again, and please enjoy! GENERAL NOTES LOCATION & VENTILATION The CONTROL MASTER preamplifier must be installed in a stable location with ample ventilation. It is recommended, if this unit is rack mounted, that you allow enough clearance on the top and bottom of the preamp such that a constant flow of air can flow through the ventilation slots. We also recommend that the preamplifier be placed at least 10 inches away from its amplifier. WATER & MOISTURE As with any electrical equipment, this preamplifier should not be used near water or moisture. SERVICING The user should not attempt to service the preamplifier beyond that described in the owner's manual. Refer all servicing other than tube replacement to Manley Laboratories. SPECIAL NOTES Tubes may become loose during transit. Straighten and press down each tube before plugging the preamplifier into the mains socket. Furthermore, do not touch the tubes after the preamplifier has been switched on, as the tubes do become very hot during operation and should only be handled after the power has been turned off and the tubes have cooled. WARNING! TO PREVENT THE RISK OF ELECTRIC SHOCK DO NOT OPEN THE CABINET REFER SERVICING TO QUALIFIED PERSONEL
