Luxman K 406 K 106 Service Manual
This is the 50 pages manual for Luxman K 406 K 106 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Luxman K 406 K 106 Service Manual (Ocr-read)
Page 1
SERVICE ; j
MANUAL
Auto Reverse Stereo Cassette Tape Deck
K-4os/K-1os
Page 2
K-406/K-106
Co ntents
Specifications ................................................................... 3
Parts Locations and Disassembly Instructions ........................................... 410 8
Adjusrmenl Procedures ........................................................ 9 to 12
Adjusrmenl Locations ...................................................... 13 [o 14
Block Diagram .............................................................. 15
Replacement of Mechanical Pans ............................................. 15 re 13
Pans Layout on EC Boards and Wiring Diagram ..................................... 1910 24
Schematic Diagram .......................................................... 25 to 23
Electrical Parts List .......................................................... 29 to 39
Parts List by Specific Countries ...................................................... 40
Exploded View (Cabinel) ...................................................... 41 to 42
Exploded View (Cassette Deck) ................................................. 43 lo 44
Cabinet Assembly Parts List .................................................... 45 to 45
Cassene Deck Assembly Pans Lisr ................................................... 47
Packing Method View ............................................................. 48
Packing Assembly Parts List ........................................................ 49
Semiconductor Lead Identifications ............................................... 50 10 55
