Page 1
- 1-2 - SECTION 1. GENERAL ❏SPECIFICATIONS MODEL LPC-LM340A/X, LPC-BM340A/X SECTION LPC-LM345A/X, LPC-BM345A/X Power supply Refer to the back panel of the unit. Power consumption 13W Mass 3.24kg External dimensions (W x H x D) 360 x 170 x 260mm Output Power 2.5W x 2 Speakers 8Ωx 2 Battery Operation DC 12V, eight C(R14) and four AA(R6) batteries (not supplied) Fequency response 100 ~18000Hz Signal-to-noise ratio 59dB T.H.D 0.7% Tuning Range 65~74MHz, 87.5~108MHz or 87.5 ~108MHz Intermediate Frequency 10.7MHz Antenna Telescopic antenna Tuning Range 522~1611kHz or 530 ~1610kHz Intermediate Frequency 450kHz Antenna Ferrite bar antenna Recording System 4 Tracks 2 channel stereo Frequency Response 125 ~8000Hz Signal to Noise Ratio 40/45dB (REC/PLAY) [General] [CD] [TAPE][TUNER] [AM] (MW) [FM] * Designs and specifications are subject to change without notice. Remote Control Operation Range Point the remote control at the remote sensor and press the buttons. Distance:About 23 ft (7 m)from the front of the remote sensor. Angle:About 30 °in each direction of the front of the remote sensor.
Page 2
- 2-1 - SECTION 2. ELECTRICAL ❏ADJUSTMENTS 1. TAPE DECK ADJUSTMENT DECK MODE TEST TAPE TEST POINT ADJUSTMENT ADJUST FOR DECK ADJUST PLAY BACK MTT-114 SPEAKER Output Azimuth adjusting screw STOP FWD: LEFT L/R Maximum RVS FWD: RIGHT RVS: LEFT 2. RECORD BIAS ADJUSTMENT DECK MODE TEST TAPE TEST POINT ADJUSTMENT DECK ADJUST FOR REC MODE MTT-5511 C241 L201AUTO-RVS 85kHz±5kHz AUTO-STOP 60kHz±5kHz
