Lexicon Alex User Guide rev2
This is the 20 pages manual for lexicon Alex User Guide rev2.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from lexicon Alex User Guide rev2 (Ocr-read)
Page 1
Unpacking and Inspection After unpacking the unit, save all packing materials in case you ever need to re-ship. Thoroughly inspect the unit and packing materials for signs of damage. Report any shipment damage to the carrier at once; report equipment malfunction to your dealer. Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class B prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing device in accordance with the specifications in Subpart J of Part 15 of FCC Rules, which are designated to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: reorient the receiving antenna; relocate the computer with respect to the receiver; move the computer away from the receiver; plug the computer into a different outlet so that the computer and receiver are on different branch circuits. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the Federal Communications Commission helpful: "How to identify and Resolve Radio/TV Interference Problems." This booklet is available from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4. Notice Lexicon Part 070-09526 Rev 2 Copyright 1994, 1995 Lexicon Inc. All Rights Reserved. Printed in the U.S.A. Lexicon Inc. 3 Oak Park Bedford MA 01730 USA Telephone 781-280-0300 Fax 781-280-0490
Page 2
Table of Contents Introduction ............................................................................... 1 Front Panel Overview ............................................................... 2 Setting Audio Levels ............................................................... 3 Rear Panel Connections ........................................................... 4 Footswitch Connections ......................................................... 5 Presets and Parameters ........................................................... 6 The Presets ............................................................................ 6 About the Parameters ............................................................. 7 Parameter Settings ................................................................. 8 Loading an Effect .................................................................... 10 Editing an Effect ...................................................................... 11 Performing an Edit Compare ................................................ 12 Storing an Effect ..................................................................... 13 Using Footswitches ................................................................ 14 Bypass .................................................................................. 14 Stepping through the Registers ............................................ 14 Clearing Registers ................................................................ 14 Skipping Registers and Creating Chains .............................. 15 Specifications .......................................................................... 16
