lafayette te 22

Extracted text from lafayette te 22 (Ocr-read)

Page 2

TECHNICAL SPECIFICATIONS

Sine Wave Range ................

Square Wave Range ..............

Calibration Accuracy ............

Frequency Response ............
Output Voltage:
Load Impedance - 1M ohm ......
Load Impedance - 10M ohm . . . . .

Tube Complement ..............

20 Hz - 200K Hz in 4 bands.
Band A 20 - 200 Hz
Band B 200 - 2,000 Hz
Band C 2,000 - 20,000 Hz
Band D 20,000 - 200,000 Hz

60 Hz - 30K Hz.
(5% tilt at 60 Hz, 5% rounding
at 30K Hz.)
Read on same scales as Sine Waves

13% +2 Hz

i1.5db, 60 Hz to 150K Hz.

7 V. (max)
5 V. (max.)
