LAFAYETTE MODELS HE-ZOAWX

PH OTO FACT® Folder (Series 3, 4, 5), HE-2OWX (series a)

TRADE NAME Laiayette Models HE-ZOAWX Series a, 4, 5; HE-zawx Series 3
SUPPLIER Laiayette Radio, wry-as Liberty Ave., Jamaica 33, N. y.

TYPE SET Ac-Battery Operated 7 Tube Citizens Band Transmitter-Receiver
POWER SUPPLY iio - no Veits Ac, so Cycles (or) 12 Voit storage Buttery
RATING 51 Watts, .5 Amp. @117 Voits AC (or) 4. 3 Amp, @1244 Voits DC

TUNING RANGE Any 4 oi citizens and Channeis ithru 23
(Receiver may be crystni controued or manuaiiy tuned)
