Labgruppen ip d2400 datablad en

Page 1

www.labgruppen.com Item no. TDS-IPD2400 - 19.09.2013 Specifications IPD 2400 General Number of channels (not bridgable)2 Maximum total output power 2400 W Output voltage 100 V peak / 70 Vrms / 39.2 dBu Output current 20 Arms Max. Output Power (all ch.s driven) 2 ohms 800 W 4 ohms 1200 W 8 ohms 600 W 16 ohms 300 W Performance THD+N 20 Hz - 20 kHz @ 1 W <0.1% THD+N @ 1 kHz, 1 dB below clip <0.05% Output noise -66 dBu Signal To Noise Ratio 105 dB Channel separation @ 1 kHz >80 dB Frequency response (-3 dB) 2 Hz - 42 kHz Input impedance 18 kOhm Common Mode Rejection (CMR) >50 dB Output impedance 25 mOhm Input sensitivity for maximum output voltage 6 dBu Maximum analog input level 20 dBu Gain (all DSP controls set to 0 dB) 33.2 dB Mains power Nominal mains voltage 100 - 240 VAC Operating mains voltage 60 - 265 VAC Standby consumption <7.5 W Mains connector Locking IEC inlet Physical Dimensions (Rack rail - rear panel) W: 483 mm (19), H: 44 mm (1 U), D: 359 mm (14.1) Dimensions (over all incl. handles & rear suppor t) W: 483 mm (19), H: 44 mm (1 U), D: 431 mm (17.0) Weight 6.2 kg (13.7 lbs) Finish Black, anodized aluminium front panel. Black/grey steel chassis Connectors Analog input connectors per channel 3-pin XLR female Analog input link connectors per channel 3-pin XLR male AES input connector 3-pin XLR female AES input link connector 3-pin XLR male Output connectors per channel Neutrik speakON / Binding posts, electronically balanced Network connector RJ45 (Ethernet) Buttons Power Menu Back Mute (per channel) Power Encoder Adjust/Set LEDs Signal / Mute (per channel) Limit (per channel) Power State Approvals CE, PSE, UL 60065, CAN/CSA - C22.2, No.60065:03, FCC part 15 Class A, EN 55103-1, EN55103-2, ROHS All specifications are subject to change without notice.
