Krell kid owners manual
This is the 6 pages manual for krell kid owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from krell kid owners manual (Ocr-read)
Page 1
These products comply with the EMC directive (89/336/EEC) and the low voltage directive (73/23/EEC). Krell Industries, Inc. 45Connair Road Orange, CT 06477 3650 USA TEL 203 298 4000 FAX 203 891 2028 E MAIL krell@krellonline.com WEBSITE http://www.krellonline.com 1. Read Instructions. 2. Keep these Instructions. 3. Heed all Warnings. 4. Follow all Instructions. 5. Do not use this apparatus near water. 6. Clean only with drycloth. 7. Do not install near any heat sources such as radiators, heat registers, stoves, or other appa ratus (including amplifiers) that produce heat. 8. Unplug this apparatus during lightning storms or when unused for long periods of time. 9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as a power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 10. The KID and the Papa Dock must be placed on a firm, level surface where it is not exposed to drip ping or splashing. 11. The ventilation grids on the bottom of the KID, and the ventilation grids on the top and bottom of the Papa Dock must be unobstructed at all times during operation. Do not place flammable materi alabove or beneath the KID or the Papa Dock. 12. Before making connections to the KID or the Papa Dock, ensurethat the power is offand other com ponents are in mute or stand by mode. Make sure all cable terminations are of the highest quality, free from frayed ends, short circuits, or cold solder joints. 13. THERE ARE NO USER SERVICEABLE PARTS INSIDE THE KID OR THE PAPA DOCK. Please contact Krell if you have questions not addres sed in this guide. IMPORTANT SAFETY INSTRUCTIONS CONTACT INFORMATION Krell ®is a registered trademark of Krell Industries, Inc., and is restricted for use buy Krell Industries, Inc., its subsidiaries, and authorized agents. iPod is a trade mark of Apple, Inc., registered in the U.S. and other Countries. © 2008 by Krell Industries, Inc. All rights reserved. 2Krell / Papa Dock Krell / Papa Dock Owners Reference, v08.0 Krell / Papa Dock 11 Front Panel and Remote Control Functions for the KID 22 iPod device docking station Connect the iPod device to the KID by plug ging it into the dock connector. The iPod device takes the KID in and out of stand by. When an iPod device is connected to the dock connector, the KID automatically moves to the operational mode from stand by. When an iPod device is removed from the dock connector, the KID automatically reverts to the stand by mode. 23 Aux Input Use this input instead of the dock connector to connect any audio source via a 3.5 mm stereo phone cable. TOP AND FRONT PANEL ONLY 28 DISP Key Turns on the iPod device backlight. 29Menu Key Activates the iPod device menu function. The remote menu key does not have a held function. 30Up Directional Key Performs the iPod device up arrow function. 31 Down Directional Key Performs the iPod device down arrow function. 32 Left and Right Directional Keys or Track Keys Activate the iPod device previous and next track functions r espectively. 33 Play Key Performs the iPod device play/resume function. 34 Stop Key Performs the iPod device stop function. 35 Repeat Key Performs the iPod device repeat function. 36 Shuffle Button Performs the iPod device shuffle function. 37 Pause Key Performs the iPod device pause function. 38 Mute Key Performs the iPod device mute function. 39 Search Up/Down Keys Press and hold these keys to perform the iPod device search function. 40Album Up/Down Keys Perform the iPod device album up and down functions. 41Playlist Up/Down Keys Perform the iPod device playlist up and down functions. REMOTE ONLY 24 Power Button Press the power button or key to take the KID in and out of stand by. Power LED Color Guide When the KID is plugged into AC power, the power LED illuminates: Red The KID is in stand by mode. Blue The KID is on, in the operational mode, indicating that an iPod device is con nected. Purple The KID is on, in the operational mode, and an iPod device is not connected. 25 Bass Control Two buttons or keys control the bass tone control + or 6 dB. The bass control is within the KID and not in the iPod device. 26 Treble Control Two buttons or keys control the treble tone control + or 6 dB. The treble control is within the KID and not in the iPod device. 27 Volume Control The iPod device volume control is not active when the iPod device is connected to the KID. Two up or down buttons on the KID, or the two up or down keys on the KIDremote, con trol the volume, from 0 to 151. Press and hold both volume buttons or keys at the same time for 3 seconds. The volume locks, and the KID can be used as a source in an A / V system. Press and hold both volume buttons or keys at the same time, for 3 seconds, to unlock the volume. FRONT PANEL AND REMOTE
Page 2
FIGURE 1 The iPod device Support 5 FIGURE 2 Connecting the KID to the Papa Dock 6 FIGURE 3 KID Back Panel Connections 7 FIGURE 4 Papa Dock Back Panel Connections 7FIGURE 5 Inserting the iPod device Into the Dock Connector 9 FIGURE 6 KID Front Panel 10 FIGURE 7 KID Remote Control 11 This owners reference contains important infor mation on the placement, installation, and opera tion of the KID and the Papa Dock. Please read this information carefully. A thorough understand ing of these details will help ensure satisfactory operation and long life for your KID, the Papa Dock, and related system components. LISTOFILLUSTRATIONS Papa Dock. The Papa Dock is engineered to drive virtually any loudspeaker to realistic listening levels. The amplifier has a proprietary connection for theKID, enabling all KID output functions to route through the Papa Dock back panel. It features a sub stantial 450 W, 40,000 microfarad power supply. Left and right channels incorporate discrete, direct cou pled topology, 12 high current output devices, and terminate in WBT loudspeaker connectors. Thank you for your purchase of the KID, the Krell Interface Dock, and/or the Papa Dock. The KID can be operated alone, or docked in the optional PapaDock, a dedicated 150 W power amplifier designed specifically by Krell for use with the KID. KID. The KID is designed to deliver maximum sonic performance from an iPod device, and is the first product of its kind to utilize the fully differential out put of the internal DAC for iPod devices. Additional features include opto isolated digital con nections between the iPod device and the KID, and balanced differential Class A circuitry. Ultra low noise volume control, with digitally controlled analog bass and treble controls fine tune your listening ex perience. A full function remote control makes oper ation flexible. Balanced and single ended outputs, composite and S Video outputs, and an RS 232 control allow for a variety of connection options. To prepare the KID and the Papa Dock for opera tion, follow the steps below: STEP 1 Unpack the KID 4 Unpack the Papa Dock 4 STEP 2 Affix the iPod device Support to the KID Top Cover 4 STEP 3Install the Battery in the KID Remote 5 STEP 4 Placement Considerations 5 STEP 5` The KID / Papa Dock Connection 6STEP 6 Connect to Your System 7 Connect the KID to Your System 7 AC Power Guidelines for the KID 7 Connect the Papa Dock to Your System 8 AC Power Guidelines for the Papa Dock 8 STEP 7Insert the iPod device Into the KID Dock Connector 9 KID Power LED Color Guide 9 Papa Dock Power LED Color Guide 9 STEP 8 Operation 9 Front Panel and Remote Functions for the KID 11 SPECIFICATIONS 12 INTRODUCTION OVERVIEW Krell / Papa Dock 3 Introduction Overview List of Illustrations 10 Krell / Papa Dock Front Panel Functions Remote Control Functions 242526 2723 22 TOP ONLY 22 Docking station (see inset above) FRONT PANEL ONLY 23 Auxiliary input FRONT PANEL AND REMOTE 24Power button/key 25Bass control button/keys and display window 26Treble control button /keys and display window 27Volume level button/keys and display window REMOTE ONLY 28 DISP key (turns on iPod device backlight) 29 Menu key 30 Up dir ectional keys: iPod device up arrow key 31 Down directional keys: iPod device down arrow key 32 Left and right directional keys/Track keys (These keys correspond to iPod device Previous and Next keys) 33 Play/Resume key 34 Stop key 35 Repeat key 36 Shuffle key 37Pause key 38Mute key 39Search keys 40Album keys 41 Playlist keys FIGURE 6 KID Front Panel Docking station inset: Inset shows iPOD device support affixed to the top cover of the chassis with the dock connector below Volume Disp MuteMenu Power Album Bass Treble Playlist Track Search 24 3029 34 31 3233 28 3827 26 37 35 36 25 39 4032 41 TREB LEV Button =front panel mechanism Key =remote function mechanism FIGURE7 KID Remote Control
