Turn Room or Whole House On 1. Make sure MVP44 or MVP64 amplifier front panel power button is on (in) and the led color is orange. Note: The RB8 remote power button is not used to turn the system on. 2. Momentarily push the desired MR60 keypad source button (top row or second row) or RB8 remote input button 1-4. The RB8 remote input buttons correspond to the MR60 source button layout. The keypad led turns on and the volume is set at about 30%. 3. To turn on the whole house on one source, press and hold the desired MR60 keypad source button for 5 seconds. The source selected is playing in all rooms at about 30% volume levels. At any time when the system is on, this will override the whole house source settings and reset the all room volumes to 30%. 4. If the sources don't turn on automatically, turn them on manually or with their remote control. 5. Adjust the volume on the RB8 remote or MR60 keypad in this room only. After adjusting volume, the keypad may display the volume level on the top three pairs of MR60 keypad buttons. Turn Room or Whole House Off 1. Momentarily press the MR60 keypad "OFF" button or RB8 remote "POWER" button. If this was the only room turned on, then the whole system will shut off and the MR60 "OFF" led will be off. If any other room was turned on, only this room will shut off. 2. To shut down the whole system at any time or when the keypad "OFF" led is on, press any hold the MR60 "OFF" button or RB8 remote button for 3-5 seconds. When all the keypad LED's are out, the system is shut down. 3. Sources may have to be turned off manually or by remote. Change Sources Press another source button on the MR60 keypad (top four buttons) or RB8 remote control input button. The RB8 remote input buttons correspond to the source layout of the MR60 keypads. To start or change the whole house to one source, press and hold that source button on the MR60 keypad for 5 seconds. The volume is set to about 30%. Whole house source selection is not available on the RB8 remote. Volume Up and Down Press the volume up or down button on the MR60 or RB8 remote. Holding the button gives continuous changes. After pressing the button the MR60 may display its volume level on the top three rows of the MR60 keypad buttons. The FNC-MUTE row is the lowest setting and the top setting is the source 1-2 buttons. Blinking button LED bars indicate the minimum or maximum volume setting. Mute Momentarily press the mute button on the MR60 keypad or RB8 remote. The source led blinks. To restore the sound press the mute, volume up or down, or any source or input button and the source selected when the mute button was first pressed is restored. Function Commands The FNC button is used to change the whole house volume (only for rooms already turned on) or select one of four possible function source selections. The FNC source selections are a dealer-installed option. Note: Be very careful when turning up the whole house volume. The volume levels increase together, but rooms with their volume already set high may damage equipment when their volume is increased. ♦To change the whole house volume, first press the FNC button and release. Then quickly press and hold the volume up or down button. The whole house volume changes more gradually than when changing individual room volumes. ♦To select an external function, first press the FNC button and release. Then quickly press and release the desired function button (1 of the 4 MR60 keypad top buttons). RB8 Remote Control Functions  2002-2003 Knöll Systems. All rights reserved v1.1 Power: switches room off or whole house off(press for 5 seconds) POWER MUTE VOL - + 4 32 1 INPUT RB8 systems Input 1-4: Turns on room and selects input music source Mute: Mutes music. to restore, press mute, input 1-4 or volume up/down Volume Up/Down Press and hold for continuous volume changes
