Knoll systems ir 10 owners manual

Page 1

3. Wires can be solid or stranded , shi elded or unshi elded wi th a minimum of 28-gauge for runs under 200, 22-gauge for runs under 500 and 20-gauge for runs up to 1000. Wires can be looped from IR10 to IR10 or home run. Home runs normal ly offer more reliabilit y an d f uture f lex ibilit y. 4. IR10s can be mixed and matche d in larger systems with up to 10 infrared receivers, such as the Knoll IR21, IR22 or IR25. 5. To wire the system together, connect the IR10 12V , GND and SIG termi nals to the correspondi ng IR54 or IR55 termi nal. Prepare the wire leads to and fr om the IR10 by stripping about ¼ of the insulation from each of the three l eads. Twi st the strands ti ghtl y together so that they do not sti ck out of the connector and cause a short circuit. Strictly observe polarity. If you are connecti ng wi th the RJ45 connector you may need a RJ 45 parallelin g st rip t o parallel con nect the w ires f rom mu ltiple IR receivers. 6. Next, pl ug the si ngl e or dual emi tters i nto the IR54 or IR55 connecti on bl ock. IR10 system typical layout 7. Now plug in the PS1202 (for up to five receivers) or PS1205 for fi ve to ten recei vers. 8. The in frared sy stem is u sually lef t plu gged in all t he t ime ( to an unswi tched outl et) as i t uses very l ittl e power. 9. Test the in frared sy stem t o see if it is w ork ing properly . Brigh t su nligh t an d passiv e in frared security systems can lower the di stance that remote cont rols can work with an IR10 recei ver. If you have any questi ons or concerns, please call and ask for infrared technical support at 1 800 566 5579. The help line is open from 7:30 a.m. to 5:00 p.m., Monday to Friday, Pacific time. RJ45 Wiring Diagram IR10 front and back RJ45 Re ce iver CD IR 31A IR34A IR55 PS1202 12 V DC P ower Su pp ly Di sh IR34A 17 1 Co nn ection Blo ck No te: IR 10 s are wired in parallel 12VGN DSIG Sy stem po wer on LED IR Re ceiver Ta lkback LE D RJ4 5 RJ45 RJ45
