Klipsch promedia gmxd 21 owners manual
This is the 8 pages manual for klipsch promedia gmxd 21 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from klipsch promedia gmxd 21 owners manual (Ocr-read)
Page 1
IMPORTANT SAFETY INSTRUCTIONS! CAUTION: RISK OF ELECTRIC SHOCK! DO NOT OPEN! CAUTION! To reduce the risk of electric shock and fire, do not remove the cover or back plate of the device enclosure. There are no user serv i c e a- ble parts inside. Refer servicing to a Klipsch authorized service center. CAUTION! The international symbol of a lightning bolt inside a triangle is intended to alert the user to uninsulated "dangerous voltage" within the device enclosure. The international symbol of an exclamation point inside a triangle is intended to a l e rt the user to the presence of important operat- ing, maintenance and servicing information in the manual accompanying the device. WARNING! To reduce the risk of fire or electrical shock, do not expose this equipment to rain or m o i s t u re . 1. Read Instructions – All safety and operating i n s t ructions should be read before operating the d e v i c e . 2. Retain Instructions – The safety and operating i n s t ructions should be retained for future re f e re n c e . 3. Heed Wa rnings – All warnings on the device and in the operating instructions should be a d h e red to. 4. Follow Instructions – All operating and safety i n s t ructions should be followed. 5. Attachments – Do not use attachments not re c- ommended by the product manufacturer as they may cause hazard s . 6. Water and Moisture – Do not use this pro d u c t near water (for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet base- ment; or near a swimming pool; and the like). 7. Ventilation – Slots and openings in the cabinet a re provided for ventilation and to ensure re l i a b l e operation of the product and to protect it fro m o v e rheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This pro d u c t should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is p rovided or the manufacture r s instructions have been adhered to.8. Heat – This product should be situated away f rom heat sources such as radiators, heat re g i s- ters, stoves, or other products (including ampli- fiers) that produce heat. 9. Power Sources – This product should be operated only from the type of power sourc e indicated on the marking label. If you are not s u re of the type of power supply in your home, consult with your product dealer or the local power company. For products intended to operate from battery power, or other sourc e s , refer to the operating instru c t i o n s . 10. Polarization – This product may be equipped with a polarized altern a t i n g - c u rre n t line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should stilll fail to fit, contact your electrician to replace your obso- lete outlet. Do not defeat the safety purpose of the polarized plug. 11. Power- C o rd Protection – Power- s u p p l y c o rds should be routed so that they are not like- ly to be walked on or pinched by items placed upon or against them, paying particular atten- tion to cords at plugs, convenience re c e p t a c l e s , and the point where they exit from the pro d u c t . 12. Overloading – Do not overload wall outlets, extension cords, or integral convenience re c e p- tacles as this can result in a risk of fire or electri- cal shock. 13. Lightning and Periods of Non-Use – For added protection for this product during a light- ning storm, or when it is left unattended and unused for long periods of time, unplug it fro m the wall outlet and disconnect the antenna or cable system. This will prevent damage to the p roduct due to lightning and powerline surg e s . 14. Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for clean- i n g . 15. Object and Liquid Entry – Never push objects of any kind into this product thro u g h openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the pro d u c t .16. Damage Requiring Service – Unplug this p roduct from the wall outlet and refer servicing to qualified service personnel under the following c o n d i t i o n s : a) When the power-supply cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the pro d u c t , c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions. Adjust only those controls that are c o v e red by the operating instructions as an improper adjustment of other controls may result in damage and often will re q u i re extensive work by a qualified technician to re s t o re the product to its n o rmal operation, e) If the product has been dropped or damaged in any way, and f) When the product exhibits a distinct change in perf o rmance – this indicates a need for serv i c e . 17. Replacement parts – When re p l a c e m e n t p a rts are re q u i red, be sure the service technician has used replacement parts specified by the man- u f a c t u rer or have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazard s . 18. Safety Check – Upon completion of any serv- ice or repairs to this product, ask the service tech- nician to perf o rm safety checks to determine that the product is in proper operating condition. 19. Servicing – Do not attempt to service this p roduct yourself as opening or removing covers may expose you to dangerous voltage or other h a z a rds. Refer all servicing to qualified serv i c e p e r s o n n e l . If this unit is purchased outside of the U.S., please contact your local dealer or distributor for serv i c e center information. If purchased inside the U.S. and dealer service is not available, contact Klipsch Customer Service for a re t u rn authoriza- tion (RA) number before shipping. For furt h e r s e rvice information, contact: KLIPSCH CUSTOMER SERV I C E 3502 WOODVIEW TRACE, SUITE 200 INDIANAPOLIS, IN 46268-1104 1 - 8 8 8 - 5 5 4 - 5 6 6 5 W W W. K L I P S C H . C O M
Page 2
Signal Input Connections The GMX control module has three audio inputs (see Fig. 4A): Toslink optical digital, coaxial digital (orange RCA jack), and stereo analog (red and white RCA jacks). Use these inputs to connect audio sources, such as a game console, DVD player, CD player, computer sound card, or TV set. Whenever possible, use one of the digital inputs, since this will allow Dolby Digital playback. Fig. 4B illustrates a setup in which a game console, DVD player, and TV set are connected to the GMX D-5.1. I m p o rtant Note: Each input demands a part i c u l a r type of cable and a matching output on the sourc e component. The optical digital input re q u i res a To s l i n k f i b e r-optic cable. The coaxial digital input re q u i res a coaxial cable with RCA plugs on each end. To ensure reliable operation, use a cable labeled for video or digital audio connections. The stereo analog input re q u i res a pair of ord i n a ry shielded audio cables with RCA plugs on each end. If you are connecting the analog inputs to a device that has a minijack output, use the supplied miniplug-to-RCA adaptor. Speaker Setup The subwoofer re q u i res an AC power connection (do not plug it in until setup is completed). All five satellite speakers and the control module connect to the sub- w o o f e r, which provides the power for all channels. Set up the speakers as follows: 1) Place the satellite speakers around the area where you will be sitting, more or less as illustrated in Fig. 1. The center speaker should be directly above or below your TV or monitor (the satellites are magnetically shielded to prevent picture interf e rence). Place the left and right front speakers to either side and equidistant f rom the screen. Place the surround (rear) speakers to the left and right and slightly behind the seating are a and facing in toward it. If possible, all five satellites should be about the same distance from the seating a re a . 2) The subwoofer can go virtually anywhere that is convenient, but we recommend placing it in the fro n t soundstage of your system and, if possible, against a wall or in a corn e r. 3) Using the five supplied speaker cables, connect the outputs on the back of the subwoofer to the matching satellites, as shown in Fig. 2. The striped wire should be connected to the red speaker term i n a l . 4) Using the supplied multipin DIN cable, connect the DIN output on the back of the system control module to the DIN input on the back of the subwoofer (see Fig. 2). 5) The satellite speakers attach to their pedestal bases via a ball socket that allows a very wide range of motion. Adjustments are simple as illustrat- ed in Fig. 3. ProMedia® GMX D-5.1 Welcome to the Klipsch ProMedia® GMX D-5.1 speaker system. The GMX D-5.1 is a high-perf o rm- ance powered speaker system consisting of five small, identical satellites and a single subwoofer. It is operat- ed from a compact, easy-to-use control module with built-in Dolby Digital and Dolby Pro Logic II surro u n d decoders. Although designed primarily for use with game consoles, such as the Microsoft Xbox™ a n d Sony PlayStation® 2, the GMX D-5.1 will also deliver excellent sound as a multimedia speaker system for a personal computer or even as the audio portion of a small home theater. I M P O RTANT NOTE: Before You Begin Do not plug in the GMX D-5.1 subwoofers power c o rd until all other wiring is completed, and do not disassemble the system before you have unplugged the subwoofers power cord. Be especially careful not to connect or disconnect any signal cables while power is applied. Failure to observe this caution may result in loud hums, buzzes, or pops that will at the v e ry least be annoying and that in the extreme may damage your speakers. Unpacking C a refully remove the system components from the c a rt o n : - 1 Subwoofer - 5 Satellite speakers on pedestal bases - 1 Digital preamplifier and control module - 1 Multipin control cable with DC supply cord - 5 Speaker cables with RCA connector on one end - 1 Stereo miniplug-to-RCA-sockets adaptor - 1 AC power cordF I G UR E 2 F I G U R E 1 F I G U R E 31. Loosen ( c o u n t e r- c l o c k w i s e ) 2. Adjust 3. Ti g h t e n
