Klipsch procinema owners manual
This is the 12 pages manual for klipsch procinema owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from klipsch procinema owners manual (Ocr-read)
Page 1
General IntroductionPg. 2-5 Safety Amplification Wire Gauge CrossoversPg 5-6 General Aiming Goals Behind-The-Screen and Stage SystemsPg 6 Placement Considerations Vertical Horizontal Mechanical Installation for KPT-MCM-4 GrandPg 7 Mechanical Installation for KPT-MCM-3 GrandPg 7 Mechanical Installation for KPT-Jubilee™Pg 8 Mechanical Installation for KPT-941-TPg 8 Mechanical Installation for KPT-941Pg 9 Mechanical Installation for KPT-904Pg 9 Mechanical Installation for KPT-535Pg 10 Mechanical Installation for KPT-325Pg 10 Mechanical Installation for KPT-684Pg 11 Mechanical Installation for KPT-484Pg 11 Mechanical Installation for KPT-250, KPT-200, KPT-100Pg 11 Mechanical Installation for KPT-110Pg 11 Surround Sound System InstallationPg 11 Screen Sound System Setup and AlignmentPg 12 Wiring Detail ExamplePg 13 System SpecificationsPg 13 Delay Settings Pg 13 Crossover FrequenciesPg 13 Contact and Service InfoPg 14T a b l e o f C o n t e n t s
Page 2
After assembling the speakers, but prior to operation, be sure that wiring connections are correct and that the installed systems are free from problems, utilizing the following steps: 1) At the loudspeaker component end of the cable run, "short" the positive and negative connections for each frequency section together, and verify that your resistance meter reads the short when measured from the amplifier end. 2) Verify that all amplifier channels and speaker components have been wired correctly and are in proper polarity. 3) Set the electronic crossover and amplifier channels as per manufacturer recommended settings. Refer to the speaker component specifications for each system. 4) With a low level pink noise or frequency generator signal source, verify that the low frequency amplifier and processor outputs for each of the systems is feeding the proper speaker component(s). Do the same for all of the amplifier and speaker sections, across all of the installed systems. 5) After pre-testing the system as indicated above, verifying operation and completing a basic gain staging setup, to check for rattles, buzzes or vibrations from the hardware, use a variable frequency oscillator or pink noise source to "sweep" the system between 20Hz and 1000Hz at LOW, MEDIUM, and then HIGH volume. 6) Complete a preliminary gain staging of the entire system per applicable processor specifications, then verify that component aiming properly addresses listening requirements throughout the house. 7) Complete proper final gain staging per processor recommendations.S cre en Sou n d S y st em Set u p a nd A lig nm e ntFig. 22 Fig. 23Me ch a ni ca l In st al la ti on D ra wi ng s f or K PT -4 84 a nd KP T- 68 4 Please refer to figures. 22 and 23. These figures provide dimensions required for creating baffles or for proper placement behind the screen. Connectors can be made to the system by using the terminator panel located on top of the unit. KPT-684 KPT-484
