Klipsch P 39F Owners Manual
This is the 11 pages manual for Klipsch P 39F Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Klipsch P 39F Owners Manual (Ocr-read)
Page 1
Page 2 Page 3 1. READ these instructions. 2. KEEP these instructions. 3. HEED all warnings. 4. FOLLOW all instructions. 5. DO NOT use this apparatus near water. 6. CLEAN ONLY with dry cloth. 7. DO NOT block any ventilation openings. Install in accordance with the manufacturers instructions. 8. DO NOT install near any heat sources such as ra - diators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. ONLY USE attachments/accessories specified by the manufacturer. 10. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 11. UNPLUG this apparatus during lightning storms or when unused for long periods of time. 12. REFER all servicing to qualified service person - nel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Important Safety Instructions General Cautions This symbol indicates that there are important operating and maintenance instructions in the literature accompany- ing this unit. This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit. WARNING: To reduce the risk of fire or electrical shock, do not expose this ap - paratus to rain or moisture. WARNING: Voltages in this equipment are hazard- ous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel. CAUTION: Changes or modifications not expressly approved by the manufacturer could void the users authority to operate. CAUTION! Risk of electRic shock do not open - When making or changing any connections to your system, switch all the electronics OFF. - Do NOT listen to music for long periods at extreme volume settings. Doing so can perma- nently damage your hearing. - When running loudspeaker cables, do not trail them over open floor spaces where they could cause an accident. Cover them or route them around potential troublespots. - Before switching on your sound system, turn the volume level down. After switching the system on, turn the level up gradually. - Do not use extreme settings of Treble, Bass or EQ. Ideally set the tone controls flat and turn any EQ off. - These loudspeakers are extremely heavy. Do not move them by yourself. Always get help. If you are using the floor spikes: - Spikes are sharp! Exercise extreme caution when using spikes. - Do not drag the loudspeaker. Lift the speakers off the floor and set them down carefully when changing their location. - Be especially careful not to place a spiked loudspeaker in areas where there may be hidden obstacles that could get damaged. - Some floor surfaces can be damaged by spikes. If you are unsure, consult your flooring contrac- tor for advice before using spikes, or use the spike seats. Introduction For over 60 years, our engineers have sought the ultimate: a loudspeaker that could reproduce recorded music with all the passion of a live performance. The Palladium™ Series approaches aural perfection, while making a visual statement that is every bit as elegant and passionate as the sound. The Palladium Series P-39F floorstander represents the epitome of loudspeaker technology, with remarkable clarity throughout the dynamic range and bold styling. Today, Klipsch Group, Inc. is a global force, and this flag - ship loudspeaker reflects that leadership status; design and engineering teams from the United States collabo - rated with colleagues from Germany and China to plan and execute the Palladium project. In designing the Palladium P-39F cabinet, we first considered the Klipsch heritage and unique approach to acoustic design. Trends in home interior and furniture were also factored in, as was the current audio market landscape. The result is a speaker that flawlessly melds classic Klipsch® audio with the latest in home furniture trends. The striking boat-tail design hints at the power and performance in- side, while maintaining a high degree of sophistication and beauty. More importantly, the arched shape of the P-39F flagship loudspeaker actually contributes to its remarkable sound by breaking up standing waves at higher frequencies. Power. Detail. Emotion. Combined, these qualities are the embodiment of our core philosophy. And all are expressed-beautifully-in the brilliant Palladium P-39F loudspeaker. We invite you, our customer, to share with us the pride of ownership in this extraordinary product for many gratifying years.
Page 2
Page 4 Page 5 Preparing the Loudspeaker Getting Started Unpacking Please follow the unpacking instructions fully and in the order shown below. These loudspeakers are heavy! Do not lift or move these speakers by yourself. Always have someone help you. 1 3 5 4 2 Open the carton flaps Lightly tape each flap to the box with short pieces of tape Remove the top packing piece Remove the Grille box Remove the Accessories box Remove the Owners manual and gloves Carefully invert the carton Lift off the carton Lift off the center and base packing pieces The loudspeaker is ready for connection - The grille box contains: one upper grille; one lower grille. - The Accessories box contains: four long spikes; four short spikes; four spike seats; two bi-wiring straps: one Allen wrench. - There is a pair of gloves located in a pocket in the side of the packing carton beside the Owners manual. Identify all the components. If any item is missing or damaged, report this immediately to your Klipsch dealer and the transport contractor for action. Connection Procedure: There is a specific procedure to be followed: - Switch off and unplug the amplifier/s and all source electronics from the mains power. - Place both loudspeakers in the general area where you want them. - Place each loudspeaker on its side, in its partial packing, as described in the unpacking instructions. - Connect each loudspeaker. - Attach the spikes following the instructions under the finalizing the assembly section of this manual. - Position the loudspeaker cable between the rear spikes. - Stand the loudspeaker upright, using great care not to damage connecting cables, furniture or the floor. - Lift off the top packing piece and the protective cloth bag. - Run both sets of loudspeaker cables to the amplifier. - Connect the amplifier. - Finalize the position of the loudspeakers. - Finally, fit the grilles (if desired). TAKE CARE NOT TO TOUCH THE DRIVE UNITS WHEN YOU MOVE THE LOUDSPEAKERS AROUND. TO PRESERVE THE FINISH, USE THE PROVIDED GLOVES WHEN HANDLING YOUR LOUDSPEAKERS. Fitting and Removing the Grilles The grilles are magnetically attached to the cabinet. Specially designed magnets are housed inside the front wall of the loudspeaker, so that if you wish to operate the loudspeaker with the grilles removed, no grille mounting hardware is visible. This preserves the smooth lines of the loudspeaker. To fit the grilles: Fit the top grille first and line it up with the top and sides of the cabinet. There is a small lip on the top of the grille that should rest on the top of the cabinet. Now, fit the lower grille, lining up the top of the lower grille with the bottom of the upper grille. You may now remove the top grille if you wish. Although operating the P-39F loudspeakers with the grilles on or off is a matter of personal taste, moving or connecting the loudspeakers should always be done with the grilles removed. Be especially careful not to touch the drive units. Whats in the box?
