Klipsch P 312W Owners Manual
This is the 9 pages manual for Klipsch P 312W Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Klipsch P 312W Owners Manual (Ocr-read)
Page 1
Page 2 Page 3 1. READ these instructions. 2. KEEP these instructions. 3. HEED all warnings. 4. FOLLOW all instructions. 5. DO NOT use this apparatus near water. 6. CLEAN ONLY with dry cloth. 7. DO NOT block any ventilation openings. Install in accordance with the manufacturers instructions. 8. DO NOT install near any heat sources such as ra - diators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. DO NOT defeat the safety purpose of the polar - ized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wider blade or the third prong are provided for your safety. If the pro - vided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. ONLY USE attachments/accessories specified by the manufacturer. 12. USE only with a cart, stand, tripod, bracket, or table specifiedby the manufacturer, or sold with the ap - paratus. When a cart is used, use cau- tion when moving the cart/apparatus combina- tion to avoid injury from tip-over. 13. UNPLUG this apparatus during lightning storms or when unused for long periods of time. 14. REFER all servicing to qualified service person - nel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. DO NOT expose this apparatus to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the appara- tus. 16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from the AC receptacle. 17. The mains plug of the power supply cord shall remain readily operable. Important Safety Instructions The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons. WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture. WARNING: Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. WARNING: Danger of explosion if battery is incor - rectly replaced. Replace only with same or equiva- lent type. No naked flame sources – such as candles – should be placed on the product. WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel. Place the equipment near a main power supply outlet and make sure that you can easily access the power breaker switch. WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back panel or included power supply of the product. Operation from other voltages other than those indicated may cause irreversible damage to the product and void the products warranty. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into voltages in which the product was not designed to operate. If the product is equipped with a detachable power cord, use only the type provided with your product or by your local distributor and/or retailer. If you are unsure of the correct operational volt - age, please contact your local distributor and/or retailer. CAUTION! Risk of electRic shock do not open Getting Started Unpacking This subwoofer is heavy! Do not lift or move this subwoofer by yourself. Always have someone help you. - Powercord - The grille box contains: one grille for the front of the subwoofer. ( The side grilles are installed at the factory and should not be removed.) - The Accessories box contains: remote control, calibration microphone with storage bag, microphone tripod and microphone cable. - There is a pair of gloves located in a pocket in the side of the packing carton under the Owners manual. Identify all the components. If any item is missing or damaged, report this immediately to your Klipsch dealer and the transport contractor for action. Whats in the box?
Page 2
Page 4 Page 5 Preparing the Loudspeaker Connection Procedure: There is a specific procedure to be followed: - Switch off and unplug the amplifier/s and all source electronics from the mains power. - Place the subwoofer in the general area where you want it. - Connect the subwoofer following the instructions under the connecting the subwoofer section of this manual. - Finalize the position of the loudspeakers. - Fit the front grille (if desired) TAKE CARE NOT TO TOUCH THE DRIVE UNITS WHEN YOU MOVE THE SUBWOOFER AROUND. TO PRESERVE THE FINISH, WHEN HANDLING YOUR SUBWOOFER USE THE GLOVES THAT ARE PROVIDED. Fitting and Removing the Grilles To fit the front grille: align the posts on the grille with the post cups on the front of the subwoofer and gently press on the grille. Use care to ensure that the grille clears the aluminum control panel extrusion area around the logo. Do not strike or forcibly press on the grille or grille posts as damage to the grille or finish of your subwoofer could occur. The round side grilles cover the two passive radiators and come pre-installed from the factory. They are attached via rubber capture posts to special fasteners on the passive radiators. If these grilles should ever need to be re- installed, make sure you orient them properly so that the curve of the grille follows the curve of the subwoofer side panel and gently press them back into place. Although operating the P-312W subwoofer with the front grille on or off is a matter of personal taste, moving or connecting the subwoofer should always be done with the front grille removed. Be especially careful not to touch the drive unit. Positioning Subwoofers 6 - 16 LFE 2 LFE 1 CENTER Never allow objects or furniture to impede the subwoofer or place objects on top of it! Positioning your Palladium Series subwoofer Klipsch powered subwoofers are designed to reproduce deep bass and deliver the impact that makes your movies and music come alive. Typically, optimum performance will result if you place your subwoofer in a corner of the room on the same wall as your front channel speakers. Please note that room placement can have a dramatic effect upon the performance of your powered subwoofer. Corner placement, as suggested above, will increase the amount of bass output; placing the subwoofer along the middle of a wall, or out in the room will decrease the amount of bass output. Experiment with a number of different placement options and control settings to find the one that best suits your particular room and preferences. When choosing your subwoofers location, keep in mind that you will need to connect the subwoofers built-in amplifier to an AC power outlet. The Palladium Series subwoofer features Klipschs proprietary Adaptive Room Correction. This patent-pending technology will identify the major acoustic anomalies in the low frequency range of your listening rooms acoustics and compensate for them automatically. While the corrected response may at first sound like a reduction in bass quantity, the benefit is a much higher quality bass reproduction featuring audibly faster tran - sient response and more noticeable extension of extremely low frequency program material. (See the Adap - tive Room Correction section of this manual for further information on this feature.) L R
