Kenwood X 92 4440 00 Service Manual

This is the 18 pages manual for Kenwood X 92 4440 00 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 18
Kenwood X 92 4440 00 Service Manual

Extracted text from Kenwood X 92 4440 00 Service Manual (Ocr-read)

Page 2

X92-4030-0X
X92-4440-0X

NOTE FOR HANDLING MECHANISM ASSY

N Pick is under the finger, it N Dont touch the lever be- N Don't have the center of
may touch. cause the trigger lever entrance because the disc
comes off. insertion mouth is trans-

formed.

PICK Up - Don't touch in the frame, since grease is
applied to the parts.

SPINDLE MOTOR - Don't applied grease to the roller.
- Don't touched PICK and SPINDLE MOTOR.

ROLLER
