TK-3212/3217

GENERAL/SYSTEM SET-UP

INTRODUCTION

SCOPE OF THIS MANUAL

This manual is intended for use by experienced technicians
familiar with similar types of commercial grade
communications equipment. It contains all required service
information for the equipment and is current as of the
publication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.

ORDERING REPLACEMENT PARTS

When ordering replacement parts or equipment information,
the full part identification number should be included. This
applies to all parts, components, kits, or chassis. If the part
number is not known, include the chassis or kit number of
which it is a part, and a sufficient description of the required
component for proper identification.

Unit
Model TX-RX Unit Frequency range Remarks
&destination
TK-3ZIZ K,M X57-7l30-10 450~490MHZ
TK-3212 KZ' x57-713o-11 470~512MH2 'Fli38'85MHZ
M2 LOC : 38.4MHZ
TK-3217 M X57-7l30-21 440~480MHZ

SYSTEM SET-UP

Merchandise received

PERSONAL SAFETY

The following precautions are recommended for personal

safety:

I DO NOT transmit until all RF connectors are verified secure
and any open connectors are properly terminated.

I SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.

I This equipment should be serviced by a qualified technician only.

SERVICE

This transceiver is designed for easy servicing. Refer to
the schematic diagrams, printed circuit board views, and
alignment procedures contained within.

License and frequency allocated by FCC

Choose the type of transceiver

Frequency range (MHZ) RF power Type
TX/RX 450~490 4.0W TK-3212 (K,M)
TX/RX 470~512 4.0W TK-3212 (K2,M2)
TX/RX 440~480 4.0W TK-3217 (M)

Transceiver programming

A personal computer (IBM PC or compatible), programming

interface (KPG-22), and programming software (KPG»|00D)

are required for programming.

(The frequency, TX power HI/LOW, and signaling data are programmed
for the transceiver.)

( - - ) YES KRA-23 or KRA-27
A 7
re you usrng the optional antenna. 0 ti | t

NO

< - - )YES KMC-l 7 or KMC-21
m 7
Are you usrng the speaker Icrophone. S k r i r

NO

I Delivery I

(Option)
