Kenwood SP 820 Service Manual
This is the 4 pages manual for Kenwood SP 820 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Kenwood SP 820 Service Manual (Ocr-read)
Page 1
KENWOOD
SERVICE MANUAL
MF'LYERS
moms "an." Law mam
EOO
oi.
EXTERNAL SPEAKER
Page 2
SP-820
SPEOIFIOATIONS/ FEATURES/ FILTER SELECTOR OIROUIT/
FILTER SWITCH OPERATIONS
SPECIFICATIONS
Speaker ............. 12 cm
Nominal max. Input ..... 2 W
Impedance ............ 8 9
Frequency Characteristic . .
100 Hz ~ 5 kHz
Filter Cut-off Frequency
LOW ............. 400 HZ / -3 dB
HIGH 1 ............ 3 kHZ / -3 dB
HIGH 2 ........... 1.5 kHZ/ -3 dB
Filter Attenuation ..... -6 dB/ Oct
Size ................ W 169 (169) mm
H 153 (167) mm
D 335 (348) mm
Figures in ( I are maxesizes includ-
ing projected parts.
Weight .............. 2.5 kg
FEATURES
1,
2.
Adoption of a graceful design which esthetically match-
es the T8820 series.
Installation of band selector filter (attenuation possible
by series insertion of L in high range and C in low
range).
Selection of 2 input systems (switching between IN-
PUT A and B).
Feasibility of monitoring voice with a head-phone,
after passing through the band-pass filter.
FILTER SELECTOR CIRCUIT
This speaker system is provided with a circuit which
offers a filter effect by the characteristics shown below.
400 Hz
1.5 kHZ 3 kHz
LOW HIGHZ HIGH1
Each filter switch offers the following functions:
FILTERS (LOW)
FILTER ON makes attenuation at 400 Hz and below
(400 Hz / #3 dB).
FILTERS (HIGH 1)
FILTER ON makes attenuation at 3 kHz and above
(1 kHz / 73 dB).
FILTERS (HIGH 2)
FILTER ON makes attenuation at 15 kHz and above
(1.5 kHz / -3 dB).
Combined use of these filter switches can make the
following frequency characteristics:
FILTER SWITCH OPERATIONS
1.
2.
3.
When LOW and HIGH 1 are pressed simultaneously,
the resultant frequency band is 400 Hz ~ 3 kHz,
When LOW and HIGH 2 are pressed simultaneously,
the frequency band is 400 Hz ~ 1.5 kHz.
When LOW, HIGH 1, and HIGH 2 are pressed simulta
neously, the frequency band is 400 Hz ~ 1.5 kHz,
Suggestions for practical filter operations are obtain-
able from "Use of Filter" in the instruction manual.
