RXDEV333(K)COVER1,1P(( 8/16/00 1:48 PM «Ks/2 /\

FIXD-V333/V535//V636/V737

CONTENTS / ACCESSORIES

Contents

CONTENTS / ACCESSORIES ..
EXTERNAL VIEW ......................
DISASSEMBLY FOR REPAIR...

PC BOARD ......................
SCHEMATIC DIAGRAM ..
EXPLODED VIEW

aloh'm'ooix)

CIRCUIT DESCRIPTION. PARTS LIST ..............

ADJUSTMENT ................. .. PARTS DESCRIPTIONS ..54
WIRING DIAGRAM ................................................... 1 SPECIFICATIONS .................................................... 55
Accessories

FM indoor antenna (1)
(T90-0836-05)

AM loop antenna (1)
(T90-0852-05)

Remote control unit (1)
(A70-1415-05): RC-V535

unno'ooooooona
a momentum
on I onooooun

oooooouo

oooo o

Batteries (Re/AA) (2)

Battery cover (A09-1192-08)

AC plug adaptor (1)

Speaker cords
(E03-0115-05)

Video Cord (1)
(E30-1427-05)

M type only

XD-V636 (2)
XD-V737, XD-V737S (4)
Provided in the speaker package

Use to adapt the plug on the power cord to the Shape
of the wall outlet.
(Accessory only for regions where use is necessary.)

r\
\/

System configuration

SYSTEM MAIN UNIT DESTINATION SPEAKER SP CORD PARTS No
XD-V333 RXD-V333 MI LS-N373 E30-5829-08
XD-V333S RXD-V333S M2 LS-N373 E30-5829-08
XD-V535 RXD-V535 MIV LS-N573 E30-5829-08
XD-V535-GR RXD-V535-GR M1 LS-N573-GR E30-5829-08
XD-V53SS RXD-V5358 M2 LS-N573 E30-5829-08
XD-V53SS-H RXD-VSBSS-H M2 LS-N573-H E30-5829-08
XD-V636 RXD-V636 MI LS-N853 E30-5475-08
XD-V737 RXD-V737 MIV LS-N773 E30-5876-08
XD-V737S RXD-V737S M2 LS-N773 E30-5876-08
Cautions

Operation to reset

The microcomputer may fall into malfunction (impossibility
to operate, erroneous display, etc.) when the power cord is
unplugged while power is ON or due to an external factor.
In this case, execute the following procedure to reset the
microcomputer and return it to normal condition.

Unplug the power cord from the power outlet then,
while holding the ENTER key depressed, plug the
power cord again.

(Main unit only)

0 Please note that resetting the microcomputer clears the
contents stored in memory and returns it to the condition
when it left the factory.
