RXDaMSS(K)]NT1P 03.1.7 0:11 PM N? Z

RXD-M35

CONTENTS / ACCESSORIES / CAUTIONS

Contents

CONTENTS / ACCESSORIES / CAUTIONS ............. 2
EXTERNAL VIEW ..............
CIRCUIT DESCRIPTION
ADJUSTMENT.
PC BOARD ......

Accessories

SCHEMATIC DIAGRAM .......................................... 19
EXPLODED VIEW ..

PARTS LIST .......... ...26
SPECIFICATIONS .. ...... .Back cover

AM loop antenna (1)
(T90-0846-08)

FM indoor antenna (1)
(T90-0861-08)

Remote control unit (1)
(A70-1568-05): E,T,H type
(A70-1569-05): K,X type

Batteries(R6/AA) (2)

Cautions

Operation to reset

The microcomputer may fall into malfunction (impossibil-
ity to operate, erroneous display, etc.) when the power
cord is unplugged while unit is ON or due to an external
factor. In this case, execute the following procedure to
reset the microcomputer and return it to normal condi-
tion.
0 Please note that resetting the microcomputer clears
the contents stored in and it returns to condition
when it left the factory.

Unplug the powercord from the power outlet, then while

holding the POWER or Q) key depressed, plug the power
cord again.

0 POWER
2 IE1) or 2 El)

Lstanahy/Iimer @

After resetting the microcomputer, the display will show
as follow:

L standby/timer

Note related to transportation and movement
Before transporting or moving this unit, carry out the follow-
ing operations.

0 Remove the CD from the unit.
9 Press the CD NII key.

9 Wait for some time and verify that the display
appears as above.
0 Wait a few seconds and turn the unit OFF.

CLASS 1
LASER PRODUCT

The marking ol this product has been classified as Class 1. It means
that there is no danger of hazardous radiation outside the product.

Location: Back panel

The marking of products using lasers (For countries other than U.S.A., U.S.-Military and Canada)

CAUTION
vIsIeLE mssn RADIATION
WHEN OPEN. DO NoT STARE
INTo EEAM on VIEW DIRECTLY

WITH 0than INSTRUMENTS.

Inside this laser product, a laser diode classified as Class 3A laser
radiation is contained as alerted by the internal caution label shown
above. Do not stare into beam or view directly with optical instruments.
