Page 2
r\
\/
RXDEDV9(K) COVER1,1P( 00.11.13 0:15PM «5? 2
RXD-DV9
CONTENTS / ACCESSORIES / CAUTIONS
Contents
CONTENTS / ACCESSORIES / CAUTIONS...
EXTERNAL VIEW/ DVD BLOCK DIAGRAM ..
BLOCK DIAGRAM ...........................................
CIRCUIT DESCRIPTION.
ADJUSTMENT ...........
WIRING DIAGRAM....
Wary
PC BOARD ........................
SCHEMATIC DIAGRAM.
EXPLODED VIEW .............
PARTS LIST ....................
SPECIFICATIONS ..........
Please contact our KENWOOD Service Department in your side if you want the service information; Circuit
Description, Full Described Parts List and so.
Information is available to you by internet from us.
Accessories
FM indoor antenna (1)
(T90-0875-08)
Loop antenna (1)
(T90-0874-08)
Remote control unit (1)
(A70-1499-08): TE
(A70-1500-08): MM2
(A70-1501-08): x
Batteries (ROS/AAA) (2)
Video cord (1)
(E30-1427-05)
Speaker cords (Provided in the Speaker package)
LS-DV9
Front (for Europe and U.K.) (2)
speakers
LS-DV10 _
(for other countries)
Surround
Speakers CRs-Dve (3)
*AC plug adaptor (1)
(E03-0115-05)
* Use to adapt the plug on the
3" power cord to the shape of
the wall outlet.
(Accessory only for regions
where use is necessary.)
System configuration
SYSTEM MAIN UNIT DESTINATION SPEAKER SP CORD PARTS NO. SPEAKER SP CORD PARTS NO.
XD-DV9 RXD-DV9 TE LS-DV9 E30-5535-05
MX LS-DV10 E30_5838_08 CRS-DV9 E30-5542-05
XD-DV9(M2) RXD-DV9(M2) M2
Cautions
Operation to reset
The microcomputer may fall into malfunction (impossibility to
operate, erroneous display, etc.) when the power cord is un
plugged while power is ON or due to an external factor. In this
case, execute the following procedure to reset the microcome
puter and return it to normal condition.
Pull the plug from the receptacle, wait a few seconds,
and then insert the plug again while holding the ENTER
key down. "INITIALIZE" will be displayed and the unit
will be initialized.
o Please note that resetting the microcomputer clears the contents
stored in and returns and to condition when it left the factory.
