INTRODUCTION

The purpose of this manual is to acquaint you
with the operating features of your new amplifier.
You will notice that in every detail of planning,
engineering, styling, operating convenience, and
adaptability, we have sought to anticipate your
needs and desires.

In order to make the best use of your new
amplifiers, we suggest that you carefully read
through this INSTRUCTION MANUAL and the

DIRECT DRIVE AMPLIFIER SYSTEM DESCRIP-
TION furnished together.

Knowing how to set up your amplifier, to the
best advantage, will enhance your listening pleasure
right from the start. You will also become aware
of .the ease with which you can adjust your amp|i~
fier to meet your special requirements.

(This INSTRUCTION MANUAL is available
for both L-07C and L-07M amplifiers.) If any
power amplifiers other than L-07M are used, please
refer to the relevant instruction manuals prepared
for them.

SERIAL NUMBER

Record your SERIAL NUMBER on the spaces
designated on the warranty card. You will find
the serial number on the back of the unit.

AFTER UNPACKING

After unpacking, we recommend you inspect
and examine the unit for any possible shipping
damage. If your unit is damaged or fails to operate,
notify your dealer immediately. If your unit was
shipped to you directly, notify the shipping com-
pany without delay. Only the consignee (the per-
son or company receiving the unit) can file a claim
against the carrier for shipping damage.

We recommend you retain the original carton
and packing materials to prevent any damage should
you transport or ship your unit in the future.

WARNING:

TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOIS-
TURE.

2 L 07C~LaO7Mle

NOTE
1. Units shipped to the
- ADA are designed to

. ._ 120 volts AC only
the Scandinavian co
ed to be operated w
_, Only. Therefore the
hot equippedwith an A
tor Switch so all referen
switch throughout thi
be disregarded. "
2. Units shipped to all 0th
equipped with an A L
Switch on the rear.
at the factory to th
available in the destina

The L-O7C and L-07M operate on 110 ~ 120
volts or 220~ 240 volts AC. The AC Voltage Selec-
tor Switch on the rear panelis set to the voltage
that prevails in the area to which the amplifiers are
shipped. Before operating these units, make sure
that the position of the AC Voltage Selector Switch
matches your line voltage. If not, it must be chang-
ed to the proper setting.

To change, first remove the stopper plate and
slide the AC Voltage Selector Switch to the oppo-
site side. Then reattach the stopper plate to the
other side.

Note:
Our warranty does not cover damage caused by excessive
line voltage due to improper setting of the AC Voltage
Selector Switch.

L-07C type L-O7M type
© Stopper plate
«was;
A
V

63

1|0-IZOVD220-240V
(IZOV'V <>ZZOV~)

no-Izov <>220-24ov
(120w 4>22W~)

1. Remove screw and stopper plate.

2. Switch lever to opposite side.

3. Lock lever by attaching stopper
plate to opposite side screw.

l )

i220v~i§§8;

A A
V
(12%) 1 1°

120v
European type.

@

AC VOLTAGE SELECTOR SWITCH
