KVT-61 7DVD/647DVD
BLOCK DIAGRAM,
COMPONENTS DESCRIPTION,
MICROCOMPUTER'S TERMINAL DESCRIPTION,
TEST MODE,
ADJUSTMENT,
The items mentioned above are the same as for KVT-
717DVD.
Please refer to the service manual (853»0312-00) for
KVT-717DVD.
NOTES ON ASSEMBLING THE MECHANISM
1. Fasten Screw A so that the interval (a) will be about 5.2mm
and the interval (b) will be about 2.6mm. (The interval (a)
can be measured using a pair of vernier calipers or similar
tools.)
2. Turn B so that Position (0) will come at about the center of
interval (d).
3. Then, play the test disc and fine tune A or B so that the jitter
value would be minimized.
V
