KRF-V808OD/V808OD-SNR-8050

ACCESSORIES / CAUTIONS

Accessories

FM indoor antenna (1)

(T90-0877-05): EE1 (T90-0905-05): KP

AM loop antenna (1)
(T90-0893-05)

Remote control unit (1)
RC-R0823
(A70-1623-05): EE1
RC-R0822
(A70-1622-05): KP

Batteries (Re/AA) (2)

o 771 n
D an hezzzzzz
:13

% Mano

Color vs Model

Model Color ABB.
KRF-VBOBOD Black E
KRF-V8080D-S Silver E1
VR-8050 Black KP

Cautions

Resetting the Microcomputer

The microcomputer may malfunction (unit cannot be
operated, or shows an erroneous display) it the power
cord is unplugged while the power is ON, or due to
some other external factor. If this happens, execute the
following procedure to rese

- Please note that resetting the microcomputer will clear the
contents of the memory and return the unit to the state it
was in when it left the factory.

For the U.S.A. and Canada

Unplug the power cord from the wall outlet, then plug
it back in while holding down the POWER ONISTAND-
BY U) key.

For other countries

With the power cord plugged in, turn the POWER
ONIOFF key OFF. Then, while holding down the
ONISTANDBY (D key, press POWER ONIOFF key.

Memory back up function

approximately 1 day.

- Power mode

- Input selector settings
- Picture output

- Speaker ON/OFF

- Volume level

- BASS, TREBLE, INPUT level
- TONE ON/OFF

- LOUDNESS ON/OFF
- Dimmer level

- MD/TAPE settings

- Listen mode setting

0 Speaker settings

0 Distance setting

0 Input mode setting
OSound mode settings
0 Broadcast band

0 Frequency setting

0 Preset stations

0 Tuning mode

0 ACTIVE EQ mode

0 SPEAKER EQ mode

Please note that the following items will be deleted from the units
memory if the power cord is disconnected from the AC outlet for
