Kenwood KDCX 569 Service Manual

Page 8

KDC-M6024/G/GY/Y
KDC-MP522,X569

TEST M ODE

10. Special display when the display is all on
Pressing the Preset keys while the power is ALL OFF dis-
plays the following information.

PRESET1 Version display (8 digits, Month/Day/Hour/Minute)
(Display) SYS xxxxxxxx

PRESET 2 Serial No. display (8 digits)

(Display) S. No. xxxxxxxx

PRESET 3 Short press: View power ON time.

(The All OFF period is not counted.)

Long press/hold: Clear power ON time.
(Display) PonTim xxxxx Max. 60,000 (hours)
PRESET4 Short press: Display CD operation time.

Long press/hold: Clear CD operation time
(Display) CDTime xxxxx Max. 60,000 (hours)
PRESET 5 Short press: Display CD ejection count.

Long press/hold: Clear CD ejection count.
(Display) EjeTim xxxxx Max. 60,000 (times)

PRESET 6 Short press: Display Panel open/close count.
Long press/hold: Clear Panel open/close count.
(Display) PnCnt xxxxx Max. 60.000 (times)

FM ROM correction version information
(Display) ROM Rxxxx
If not mounting ROM correction chip set display

shows ROM RV

11. Change the condition of TUNER channel
space selection (K/M type only)
While holding the preset 1 key and 5 keys. reset the unit.

Security-related information

1. Forced Power 0N mode (All models)
Even when the security is approved, resetting the unit while
holding the Q and Preset 4 keys makes it possible to turn
the power ON for 30 minutes.
After 30 minutes have elapsed, it is not possible to return to
the previous condition unless the unit is reset again.

2. Method of registration of the security code
after EEPROM (Tuner unit assy) replacement
(Code security model)

1. Enter the test mode. (See 1. How to enterthe test mode)
2. Press the MENU key to enter the MENU mode.
3. Press and hold down the Track up/down key for 1 second
until Security is displayed.
4. Enter the code using the FM/AM/TARCK up/down keys.
- FM key: number is up
- AM key: number is dawn
- Track up key: move the cursor for right side
- Track down key: move the cursor for left side

5. Hold down the Track up key for at least 3 seconds and
the message, "RE-ENTER" appears, so once again enter
the code according to Step 3 above.

6. Press and hold the Track up key for 3 seconds until
"APPROVED" is displayed.

7. Exit from the test mode. (See 2. How to exit from the test mode)
(Note) All Clear is not applicable to the security code of

this model.

3. Simplified method of clearing the security
code (K, E Type only)

1. While the code entry is requested, press and hold the
TRACK UP key for 3 seconds while holding the DISP key
pressed. (This should turn off.)

2. Enter KCAR from the remote.

- Press the 5 key on the remote twice, and then press the
Track Up key. (This enters "K".)

- Press the 2 key on the remote 3 times, and then press
the Track Up key. (This enters "0".)

- Press the 2 key on the remote once, and then press the
Track Up key. (This enters "A".)

- Press the 7 key on the remote twice, and then press the
Track Up key. (This enters "R".)

3. The security code is cleared and the unit enters the ALL
OFF mode.

4. If you commit a mistake in the code entry, the unit enters
the code request mode again.
