Page 12
KDC-MP408U/MP438U/X492/MP5039U/MP5539U/W504iUA/
W504iUG/W5141UAY/W514iUGY/W554iU/W5641UY
TEST MODE
Key Description of display
Description
Adjustment value
memory
Displays the data that has been written in the
I>II E D E m E D D D D D E2PROM when pressing the keyfor2seconds or
longer.
NI Mode clear
E EEEEEI IE
Clear the FST adiustment mode. (Returns to
normal display and the test mode is retained.)
Switch Local Seek ON or OFF by briefly pressing [AUTO]/[Tl] key when the Local Seek ON/OFF switching is allowed in the band.
After completing the FST adjustment, if you wish to clear the test mode, you can do this using the reset button.
I Test mode specifications in CD source
Display mode default: P-Time
. Procedure in CD-DA media (KTD-02A)
Key Description of display
Description
>>I Track up procedure
Every time pressed, jumps to the track shown below.
No.9 a No.15 a No.10 a No.11a No.12 a No.13 a
No.22 a No.14 a No.9 (recursive)
But in case the disc has 8 tracks or less, playback starts
with track No.1. (For both CD-DA and compressed file
discs)
I44 Track down procedure
Goes down by 1 track from the currently played track.
1 Jump procedure
Jump to No. 28 (Scratch 0.7mm for MUSIC line vibration
testing)
2 Jump procedure
Jump to No. 14 (Blurring surface disc TOD-731 RA Tr14)
Information display
Mechanism version
Mechanism model name D E ED D D D D D D D
Display of Mechanism model name and Mechanism
version. (When key is pressed while the display in the
left is being shown, returns to servo version dispIay.)
Information display
3 Mechanism servo
version
EI E EEEEEEEE
Display of Mechanism model name and Mechanism
version. (When key is pressed while the display in the
left is being shown, returns to mechanism boot program
version dispiay.)
Information display
Mechanism boot
program version
EIEE :EEEEEEEE
Display of Mechanism model name and Mechanism
version. (When key is pressed while the display in the
left is being shown, returns to normal display.)
6 Jump procedure
Jump to No. 15. Set the volume value to 25".
(For 20Hz OdB DC protection false-operation FCT
checking)
. Procedure in CD-DA media (MP3/WMA/AAC)
Key Description of display
Description
File type display (MP3)
E EEEEEEEEEE
File type display (WMA)
E EEEEEEEEEE
Display file format just before the start of file play
back.
File type display (AAC)
EEEEEEEEEE
12
