Kenwood KDCW 4037 Y Service Manual

Page 10

KDC-W237AY/W237GY/W3037AY/W3037GY/
W31 lAY/W31 lGY/W3537AY/W3537GY/W4037Y

TEST MODE

I Special displays when all lights are on in STANDBY source

10

Key Description of display Description
Common All lights ON. E E E E E E E E E All lights ON.
1 Destination terminal E E E E E TYPE" indicates system p-com (IC1) destination, and shows
condition indication real-time condition of the destination terminal.
Development ID condition E E E .-E E Development lD-Version (system p-com: IC1)
indication
2 Serial No. display E E E E E E E E E Serial No. is displayed (8 digits)
3 Power ON time display E E E E E OO~50 is displayed for XX". When less than 1 hour,
displayed by displayed by increments of 10 minutes.
E E E 00001~10922 is displayed for XXXXX. MAX 10922 (hours)
.3 When Power ON time is displayed, press and hold for
2 seconds or longer to clear Power ON time.
4 Disc operation time display E E E D 00~50 is displayed for XX". When less than 1 hour,
displayed by increments of 10 minutes.
E E 00001~10922 is displayed for XXXXX. MAX 10922 (hours)
.4 While the disc operation time is displayed, press and hold for
2 seconds or longer to clear the disc operation time.
(Cleared only for displayed media.)
5 Disc EJECT times display Disc EJECT times display. MAX 65535 (times)
.5 While disc EJECT times is displayed, press and hold for
2 seconds or longer to clear disc EJECT times.
6 Panel open/close E E E PANEL open/close times display. MAX 65535 (times)
.6 times display Press the key for more than 2 seconds while the PANEL open/
close count is displayed and PANEL open/close count is cleared.
FM ROM correction version E E E E E E E The number is the ROM correction version number.
display E E E E E E E E When E2PROM is not installed.
E E E E E E E E E When not written in yet.
E E E E E When data not matched. (due to the difference in versions)
IAM ROM data transfer E E E E E E E E E
>>I Audio data initialization E E E E E AUDIO setting value is re-set to the test mode default value.
I44 Forced Power OFF E E E E E E E No forced power OFF
information display E E E E Forced power OFF because of missing Security Code.
(Code security supporting model)
E E E E E E Forced power OFF by communication error between system
p-com and panel.
ll<< While the forced power OFF data is displayed, press and
hold for 2 seconds to clear the data.
>I| CD information display E E E E E E E E E For the display contents, refer to CD information display
mode ON/OFF mode" in the next section.
I>II While in CD information display mode, press and hold for
2 seconds or longer to clear all CD information.
