Kenwood KD CW 410 AY Owners Manual

Page 2

E64-3294»007Eng|lsh.indd 2

4%

Contents
Safety precautions 3 Menu system 20
Menu System
Mates 4 Security Code
Touch SensorTone
Abou' MP3 and WMA 6 Manual Clock Adjustment
Synchronize Clock
Abou CD5 7 DSl (Disabled System indicator)
Selectable Illumination
General features 8 Sumeme 59mg
POWEF News Bulletin with Timeout Setting
Selecting the Source Local Seek
Volume Tuning Mode
AHEWEIOV AF (Alternative Frequency)
System Q Restricting RDS Region (Region Restrict
Audio Control Function)
Audio Setup Auto TP Seek
Speaker Setting Monaural Reception
Switching Display Auxiliary input Display Setting
Dimmer Control Text Scroll
Theft Deterrent Faceplate Power OFF Timer
TEL Mute CD Read Setting
Tuner features 12 Demonstration rnode Setting
Tuning Accessories] Installation
Tuning Mode Procedure 26 K \
Station Preset Memory , , . \/
Auto Memory Entry Connecting Wrres to Terminals 27
PresetTunin ,
9 Installation 29
RDS features 1 4
Traffic information Removrng the Unl 30
Radio Text Scroll . .
PW (Progyam Type) Troubleshooting Guide 31
ProgramType preset . . .
Changing Language for PTY Function Speclflcatlons 34
CD/Audio file/External disc control
features 1 7

Playing CD & Audio file
Playing External Disc

Fast Forwarding and Reversing
Track/File Search

Disc Search/Folder Search
Track/File/Disc/Folder Repeat
Scan Play

Random Play

Magazrne Random Play
Folder Select

Text/Title Scroll

2 l English

a

0510.6 0:51:35 PM

Page 30

Removing the Unit

Removing the hard rubber frame

Removing the Unit

'I Engage the catch plns on the removal tool and
remove the two locks on the upper level.
Upper the frame and pull it forward as shown ln
the figure.

Accessory®
Removal tool

2 When the upper level ls removed, remove the
lower two locations,

- The frame can be removed from the bottom slde in the
same manner

30 l English

EG4-3294-007Engllshjndd 30

1 Refer to the section frame> (page 30) and then remove the hard
rubber frame.

2 Remove the screw (M4 x 8) on the back panel,

3 Insert the two removal tools deeply Into the slots
on each side, as shown.

Screw (M4X8)
(commercially avarlable)

Accessory®
Removal tool
4 Lower the removal tool toward the bottom, and
pull out the unit halfway whrle pressing towards
the inslde,

/\

- Be careful to avoid mjury from the catch prns on the
removal tool,
5 Pull the unit all the way out with your hands,
being careful not to drop it,
