Page 2

Contents

Before Use 3 Appendix 1 7
Basic Operations 4 Accessories/Installation Procedure 19
B f U
Cigioslgiemm Connecting Wires to Terminals 20
Playmg MUM (CD/USB/POdl Installation/Removing the Unit 21

Listening Radio
General 6 Troubleshooting Guide 22

Removthg the Faceplate

Muting Voiume upon Reception of Phone Cail

Display Indicator
Text Display Selection

Specifications 24

Function Setting 8

<|NiTIAL SET>

Music Disc/Audio File Operation 1 2

Piay Function

Aii Random

Music Search

Music Search for iPod
Aiphabet Search

My Piayiist for iPod

iPod Controi by Hand Mode
Direct Music Search

Tuner Operation 1 5
Frequency Step Setting

Basic Operations of Remote Control 16

iPod is a trademark oiAppie Inc, registered in the U S,
and other countries.

iPhone is a trademark oi Appie Inc.

Made for iPod" means that an electronic accessory
has been designed to connect specificaiiy [0 iPod and
has been certified by the developer to meet Appie
performance standards

Works With rPhonemeahs that an electromc
accessory has been designed to connect specificaiiy
to iPhone and has been certified by the deveioper to
meet Appie periormance standards.

Appie is not responsibie for the operation of this
devrce or its compiiance With safety and regulatory
standards

2 i KDC-U446/ KDC-U346/ KDC-U5046/ KDC-U4046/ KDC-U3046

364 4531 Dfliflflien indd 2 0910 2 2 35 03 PM

m

Page 6

General

g the Faceplate
The faceplate of the unit can be detached and taken
with you, helping to deter theft.

Detach the faceplate
Press the Release button.

Reattaching the Faceplate
Refer to the following diagram when
reattaching the faceplate.

~ After pressmg the Release button, detach the faceplate
immediately if the faceplate rs ieft attached, it can iali
due to Vibration and so on

. The iacepiate is a precisiori piece oi equipment and can
be damaged by shocks orjoits.

- Keep the facepiate in its facepiate case whiie detached
(KDCVUMG/ KDCVU346/ KDCVU3046 oniy)

~ Do not place the faceplate (and the faceplate case)
in areas exposed to direct suhiight, excessive heat or
humidity. Also avoid places wrth too much dust or the
possibiiity of water spiashing

Muting Volume upon Reception of
Phone Call

The audio system automatically mutes when a call
comes in.

When a call comes in
"CALL" is displayed,
The audio system pauses.

Listening to the audio during a call
Press the [SRC] button.
The "CALEdispiay disappears and the audio system
comes back ON.

When the call ends
Hang up the phone.
The CALUdispiay disappears and the audio system
comes back ON.

. To use the TEL Mute ieature, you need to hook up the MUTE
wire to your teiephorie using a commerciai teiephone
accessory Refer to (page
20).
