Controlling the DVD Player with the Receiver Remote Use the following buttons on the receiver remote to control the DVD player: Quick Connect Guide Step 2: DVD Player HTB-403DV Connecting the DVD Player to the Receiver Connect the DVD player to the receiver as shown in the main diagram, using the supplied cables. You can plug the DVD players power cord into one of the receivers switched AC outlets. Optical Digital Cable The optical digital cable carries the digital audio bitstream to the receiver for decoding. Remove the caps from the optical digital jacks on the receiver and DVD player and store them for future use. Insert the optical cables connectors all the way into the jacks until they click into place. Do not allow the optical cable to become kinked or bent. Audio/Video Cable The audio/video cable carries the standard analog audio and composite video signals to the receiver. Use the red and white wires for the audio connections and the yellow wire for the video connection. Connecting Other Components To connect your TV and other components to the receiver, refer to pages8-9ofthereceivers instruction manual. Programming the Receiver Remote to Control the DVD Player Before you can use the receivers remote to control the DVD player, you need to pro- gram the remote. 1. While holding the remotes POWER button down, use the number buttons to enter code number 1. 2. To operate the DVD player with the receiv- ers remote, press the DVD POWER button, then press the button for the operation you want to per- form. If you dont press a button for more than 10 seconds, the remote auto- matically returnstothe receiver control mode, and you must press the DVD POWER button again before operating the DVD player. 1 1. 2. Cursor up Cursor down Cursor right Cursor left Search forward Search backward Enter Play Stop Pause Activates the DVD menu Activates the on- screen banner displayTu r n s the on- screen banner display off
