Kenwood DPX 304 Service Manual

Page 18

DPX304/DPX308U/DPX404U
DPX-MP3120/U5120/U51208

TEST MODE

0 Test mode specification with CD source
<> Operation for CD-DA media (KTD-02A)

Key Description of display Description
Normal display D D D D D D D D D D D D D P-TIME display (default)
[in] key operation enables the truck jumps in the fol-
lowing sequence.
No.9 a No.15 a No.10 a No.11 a No.12 a No.13
a No.22 a No.14 a No.9 (Return back to top)
M Truck-up =r However in the case of CD-DA disc that has 8 or
operation less tracks of recorded music, and MP3/ WMA/ AAC
discs, they are played back in order starting with
Track1.
*When displaying CD mechanism name and the ver-
sion information, returns to normal display.
Tracks down by 1 from the track currently being
i« Truck-down played back.
operation *When displaying CD mechanism name and the ver-
sion information, returns to normal display.
Jump to No.28 (For MUSIC line vibration test, Scratch
_ 0.7mm)
1 Jump operation _ _ _
*When displaying CD mechanism name and the ver-
sion information, returns to normal display.
Jump to the track No.14 (Blurring surface disc TCD-
_ 731 RA Tr14)
2 Jump operation , _ _
*When displaying CD mechanism name and the ver-
sion information, returns to normal display.
Mechanism
model name Mechanism model name (MID model: QBSO'V LOW
Mechanism D E E E D I D D D D D D D model: 9310") and mechanism version display
3 version display
(forward Mechanism servo Mechanism servo table version display
rotation) version display D E E ' D D D D D D D (Displayed only in MID model)
Mechanism boot Mechanism boot program version display
program verSIon D @ E D 1 D D D D D D D (Displayed only in MID model)
display
*Toggling action with the track iump of No.9 6 No.22
5 Jump operation sWhen displaying CD mechanism name and the ver-
sion information, returns to normal display.
Jump to the track No.15.
Set volume to 26 (20H2 OdB DC protection malfunc-
tion FCT check)
6 Jump operation *Set VOL setting value based on 13.2V supplied by
Regulated Power Supply.
*When displaying CD mechanism name and the ver-
sion information, returns to normal display.
in the display of mechanism system information,
RETURN Mode clear _
return to normal display.

18

Page 20

DPX304/DPX308U/DPX404U
DPX-MP3120/U5120/U51208
TEST MODE

4. Security code forced deletion function

0 How to transfer to the mode (E destination)
When a code is requested, press and hold [SEEK UP] key for 3 seconds while pressing [BAND] key to be transferred to the
mode, ([-][-][-][-]) will be cleared.

m mm KENWOOD rm 60'-

0 Simple security code forced deletion
Delete (Release) a security code forcibly with the operations below.
0 Enter KCAR with a remote controller.
Press [5] key of a remote controller 2 times to display K", and then press [»l] key.
Press [2] key of a remote controller 3 times to display C", and then press [»1] key.
Press [2] key of a remote controller 1 time to display A", and then press [»l] key.
Press [7] key of a remote controller 2 times to display R", and then press [m] key.
I Security is released to be a STANDBY mode.
I When incorrect remote controller code has been entered, it will be the code request mode.

5. DC error detection information display function

0 How to transfer to the mode

While pressing and holding [PRESET-S] key and [PRESET-G] key, reset-start to enter the DC error display mode.
The opening display shall be omitted for the easy recognition of the mode transfer.

In the STANDBY source, the present DC error detection status is displayed.

The transfer to this mode shall be possible even if the DC error has been detected.

This mode is cleared by reset. (The last status is not retained)

In this mode, DOP setting is unavailable (Except only for DOP TYPE display).

In the set for E destination, even if security is allowed, Power ON can be maintained only for 30 minutes.

WWW KENWOQD aux LSD:

] am: i

, seams

20

Page 55

DPX304/DPX308U/DPX404U
DPX-MP3120/U5120/U51208

PARTS LIST

CD MECHANISM ASSY (X92-6320-00) (DXM-QB10W)
CD MECHANISM ASSY (X92-6360-04) (DXM-9334W)

A N . . Desti- A N . . Desti-
Ref. No. 3 vev Parts No. Descrlphon nation Ref. No. 3 vi Parts No. Description nation
16 2A D104995-03 SLIDER DM1 28 X94-2090-00 SPINDLE MOTOR ASSY
17 28 D10A4996»02 SLlDER DM2 28 X94-2100-00 FEED MOTOR ASSY (LOAD/SLED)
18 2A D10'4997-03 LEVER DPU1 28 X93-2280-00 OPTICAL PICKUP ASSY
19 1A D10-4998-03 ARM
20 2A D104999-03 ARM
21 2A D10-7001-03 ARM
22 2A D10-7002-03 ARM
23 2A D10-7003-03 ARM
24 2A D13-2445»04 GEAR
25 2A D13-2446-04 GEAR
27 2A D13-2448-04 GEAR
28 2A D13-2449-04 GEAR
29 2A D13A2450»04 GEAR
30 2A D13A2451-04 GEAR
31 2A D13-2452-04 GEAR
32 2A D13-2453»04 GEAR
33 2A D13-2454-04 GEAR
34 2A D13-2455-04 GEAR
35 28 D13-2456-03 RACK (GEAR)
36 2A D14-1028»04 ROLLER
37 3A D21-2507-04 SHAFT
38 28 D21-2508-04 SHAFT
39 3A D23-0963-04 RETAINER
4O 38 D39-O277-15 DAMPER
41 38 D39AO278-15 DAMPER
46 18 G01-4682-34 TORSION COIL SPRING
47 3A G01-4756-04 EXTENSION SPRING
48 2A G01-4684-04 EXTENSION SPRING
49 28 G01-4685-04 EXTENSION SPRING
50 18 G01-4686»14 EXTENSION SPRING
51 3A G01-4688-14 EXTENSION SPRING
52 3A G01~4692-24 TORSION COIL SPRING
54 3A G02-1588-04 FLAT SPRING
55 18 G13-1297-04 CUSHION (CLAMPER CUSSIO
56 1B G13-1299-14 CUSHION (STROKE CUSHION
57 1A G16~1715-04 SHEET
61 18 J11-0675-03 CLAMPER
64 2A J19-7210-21 HOLDER
65 28 J19-7225-04 HOLDER
66 1B J22»0706~03 MOUNTING HARDWARE
67 1A J22-0707-12 MOUNTING HARDWARE
68 18 J90-1166A11 GUIDE
69 28 J90»1168-03 RAIL
A 1A NOB-610615 TAPTITE SCREW (M2X315)
B 28 NOB-642615 MACHINE SCREW (LOAD ARM SCREW
C 28 NOB-673505 TAPTITE SCREW (PICK SCREW)
D 28 NOB-67374 5 MACHINE SCREW (SHAFT SCREW)
E 28 NOB-673615 TAPTITE SCREW (GEAR SCREW)
F 2A N19-2335»14 FLAT WASHER
G 28 NBS-200348 B1ND|NG HEAD MACHINE SCREW
H 28 N39-1720-4B PAN HEAD MACHINE SCREW
76 2A S68~OB21~05 PUSH SWITCH
E2: DP><404U E3: DPX304 (Europe) K1: DPX308U (North America) Alndicates safety critical components.

M12DPX-U5120 M2: DPX-U512OS M3: DPX-MP3120 (OtherAreas)
55
