Kenwood Basic M 2 A Service Manual
This is the 14 pages manual for Kenwood Basic M 2 A Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Kenwood Basic M 2 A Service Manual (Ocr-read)
Page 2
DISASSEMBLY FOR REPAIR
DISASSEMBLY FOR REPAIR
l screw in the middle of large capacitors ( 0 ll
1, Remove the metalllc cabinet. Remove 2 screws at the
chassis Fl (unified with the bottom plate) ( 0), and O
3 screws at the rear panel ( e l, / © © 0
2. Remove 1 screw at the fight-forehand side ( e) and /
i .
3. Remove 6 screws ( e l.
Slide and remove the bottom plate as shown by the
arrow ( 6 l.
4. Remove 6 screws l o ), remove the panel ( 0 J.
Remove 5 screws at bottom Slde of the sub panel (9 )
and 4 screws at both sides of the sub panel ( @l,
remove the sub panel ( Q ).
For replacement of the driver/final IC, use a hex-wrench
(wosvoozzrom l® ).
