Kenwood A 4030 E Service Manual

Page 2

AR7404(K) COVER1,1P( 1/10/0010:49AM \°-/2

F\
\/

AR-404/KRF-A4030/A4030E/A4030-S

CONTENTS / ACCESSORIES / CAUTIONS

Contents

CONTENTS / ACCESSORIES / CAUTIONS
CIRCUIT DESCRIPTION.
ADJUSTMENT ................. ..
PC BOARD ................................................................ 7

Accessories

SCHEMATIC DIAGRAM
EXPLODED VIEW
PARTS LIST .................... .
SPECIFICATIONS .................................................... 27

FM indoor antenna (1)
(mousse-05)

AM loop antenna (1)
(T90-0852-05)

Remote control unit (1)
(A70-1266-05): RC-R0709 ........ KPMX
(A70-1267-05): RC-R0708 ........ E1 E2E3

Batteries (Hoe/AA) (2)

AC plug adaptor (1)
(E03-O115-05)

*Use to adapt the plug on the power
cord to the shape of the wall outlet.
(Accessory only for regions w here use
is necessary.)

Cautions

defirgfl'e Microcarpla'

If the microcomputer may malfunction (unit cannot be
operated, or shows an erroneous display) if the power cord
is unplugged while the power is ON, or due to some other
external factor. If this happens, execute the following pro»
cedure to reset the microcomputer and return the unit to its
normal operating condition.

FuuSAaflCa'ah

Unplug the power cord from the wall outlet, then
plug it back in while holding down the POWER key.

WM U.S.A. at! m
With the power cord plugged in, turn the POWER lazy
OFF. Then, while holding down the ON/ STANDBY
key, press the POWER key.

- Please note that resetting the microcomputer will clear
the contents of the memory and returns the unit to the
state it was in when it left the factory.
